B l u e B o x – M e n u O p e r a t i o n

8.2.1.5.1 GPS Port Setup

GPS menu 8.2.1.5
Por t
Off
Off
Serial 1
Serial 1
USB 1
USB 1
USB 2
USB 2
CAN1
CAN1
CAN2
CAN2
CAN3
CAN3
<–
GO Systemelektronik GmbH
GPS Por t Setup
Off
Serieal 1
USB 1
USB 2
The buttons are also status indicators
Disables the GPS connection.
If a factory-mounted GPS receiver is connected to the internal serial interface of the PC
104, then this interface is activated by the manufacturer.
If a factory-mounted GPS receiver is connected to the USB interface and USB 1 is not
allocated to a modem, then USB 1 is activated for the GPS receiver by the manufacturer
via this button.
If a factory-mounted GPS receiver is connected to the USB interface and USB 1 is allo-
cated to a modem, then USB 1 is activated for the GPS receiver by the manufacturer via
this button.
GPS module at serial interface via CAN-bus
Interface: CAN-bus serial 1
GPS module at serial interface via CAN-bus
Interface: CAN-bus serial 2
GPS module at serial interface via CAN-bus
Interface: CAN-bus serial 3
Switches back to the GPS menu.
Faluner Weg 1
24109 Kiel
www.go-sys.de
CAN1
CAN2
CAN3
<–
Germany
Tel.: +49 431 58080-0
info@go-sys.de
Page 63 / 99
Fax: -58080-11
