8. EEPROM 24LC04

The AX7103 used on chip of EEPROM, model 24LC04, Capacity of
4Kbit(2*256*8bit)comprise 2 blocks of 256byte, communication by IIC bus.
EEPROM on board is to use to study IIC bus communication method. The I2C signal
of EEPROM connected to BANK14 IO of FPGA. The figure 3-8-1 below showed the
hardware designed schematic of EEPROM.
FPGA
Below figures shows the EEPROM on board.
EEPROM pin Assignment:
EEPROM_I2C_SCL
Http://www.heijin.org
41 / 50
3-7-3 USB USB UART LED Indication
Net Name
U1
F13
E14
Figure 3-8-1 EEPROM hardware design schematic
Figure 3-8-2 EEPROM on board
Net Name
FPGA PIN
3.3V
EEPROM_I2C_SCL
SCL
EEPROM_I2C_SDA
SDA
FPGA PIN
AX7103 User Manual
P20
N15
U9
24C04
A2
A1
A0
F13
41 / 50
4
1
