Alinx AX7103 FPGA User Manual page 24

CON3 Net
PIN Name
PIN1 B15_IO0
PIN3 B16_IO0
PIN5 B15_L4_P
PIN7 B15_L4_N
PIN9 GND
PIN11 B15_L2_P
PIN13 B15_L2_N
PIN15 B15_L12_P
PIN17 B15_L12_N
PIN19 GND
PIN21 B15_L11_P
PIN23 B15_L11_N
PIN25 B15_L1_N
PIN27 B15_L1_P
PIN29 GND
PIN31 B15_L5_P
PIN33 B15_L5_N
PIN35 B15_L3_N
PIN37 B15_L3_P
PIN39 GND
PIN41 B15_L19_P
PIN43 B15_L19_N
PIN45 B15_L20_P
PIN47 B15_L20_N
PIN49 GND
PIN51 B15_L14_P
PIN53 B15_L14_N
PIN55 B15_L21_P
PIN57 B15_L21_N
PIN59 GND
PIN61 B15_L23_P
PIN63 B15_L23_N
PIN65 B15_L22_P
PIN67 B15_L22_N
PIN69 GND
PIN71 B15_L24_P
PIN73 B15_L24_N
PIN75 NC
Http://www.heijin.org
24 / 50
FPGA Voltage
PIN Level
J16 3.3V
F15 3.3V
G17 3.3V
G18 3.3V
- Ground
G15 3.3V
G16 3.3V
J19 3.3V
H19 3.3V
- Ground
J20 3.3V
J21 3.3V
G13 3.3V
H13 3.3V
- Ground
J15 3.3V
H15 3.3V
H14 3.3V
J14 3.3V
- Ground
K13 3.3V
K14 3.3V
M13 3.3V
L13 3.3V
- Ground
L19 3.3V
L20 3.3V
K17 3.3V
J17 3.3V
- Ground
L16 3.3V
K16 3.3V
L14 3.3V
L15 3.3V
- Ground
M15 3.3V
M16 3.3V
-
CON3 Net
PIN Name
PIN2 B15_IO25
PIN4 B16_IO25
PIN6 B16_L21_N
PIN8 B16_L21_P
PIN10 GND
PIN12 B16_L23_P
PIN14 B16_L23_N
PIN16 B16_L22_P
PIN18 B16_L22_N
PIN20 GND
PIN22 B16_L24_P
PIN24 B16_L24_N
PIN26 B15_L8_N
PIN28 B15_L8_P
PIN30 GND
PIN32 B15_L7_N
PIN34 B15_L7_P
PIN36 B15_L9_P
PIN38 B15_L9_N
PIN40 GND
PIN42 B15_L15_N
PIN44 B15_L15_P
PIN46 B15_L6_N
PIN48 B15_L6_P
PIN50 GND
PIN52 B15_L13_N
PIN54 B15_L13_P
PIN56 B15_L10_P
PIN58 B15_L10_N
PIN60 GND
PIN62 B15_L18_P
PIN64 B15_L18_N
PIN66 B15_L17_N
PIN68 B15_L17_P
PIN70 GND
PIN72 B15_L16_P
PIN74 B15_L16_N
PIN76 NC
AX7103 User Manual
FPGA Voltage
PIN Level
M17 3.3V
F21 3.3V
A21 3.3V
B21 3.3V
- Ground
E21 3.3V
D21 3.3V
E22 3.3V
D22 3.3V
- Ground
G21 3.3V
G22 3.3V
G20 3.3V
H20 3.3V
- Ground
H22 3.3V
J22 3.3V
K21 3.3V
K22 3.3V
- Ground
M22 3.3V
N22 3.3V
H18 3.3V
H17 3.3V
- Ground
K19 3.3V
K18 3.3V
M21 3.3V
L21 3.3V
- Ground
N20 3.3V
M20 3.3V
N19 3.3V
N18 3.3V
- Ground
M18 3.3V
L18 3.3V
-
