Below picture is the J13on board. Pin 1 and Pin2 marked on board.
Pin Assignment of expansion header J13
J13 PIN
1
3
5
7
9
11
13
Http://www.heijin.org
44 / 50
Figure 3-9-3 Expansion header J13 schematic
Figure 3-9-2 expansion header J13 on board
FPGA PIN
GND
W16
V17
U15
AB21
AA21
AB20
AX7103 User Manual
J13 PIN
FPGA PIN
2
4
6
8
10
12
14
+5V
W15
W17
V15
AB22
AA20
AA19
44 / 50
4
4
