Alinx AX7103 FPGA User Manual page 22

PIN73 B16_L6_P
PIN75 B16_L8_P
PIN77 B16_L8_N
PIN79 NC
Figure 2-10-1 is the CON1 connector on core board, and the pin1 of connector is
marked on the board.
CON2 Connector
The 80-Pin connector CON2 is used to extend the IOs of FPGA bank13 and
bank14, the voltage level of these IOs are +3.3V standard. The pin assignment of the
CON2 connector is shown in table 2-10-2：
CON2 Net
PIN Name
PIN1 B13_L16_P
PIN3 B13_L16_N
PIN5 B13_L15_P
PIN7 B13_L15_N
PIN9 GND
PIN11 B13_L13_P
PIN13 B13_L13_N
PIN15 B13_L12_P
PIN17 B13_L12_N
PIN19 GND
PIN21 B13_L11_P
PIN23 B13_L11_N
PIN25 B13_L10_P
PIN27 B13_L10_N
PIN29 GND
PIN31 B13_L9_N
PIN33 B13_L9_P
PIN35 B13_L8_N
Http://www.heijin.org
22 / 50
D14 3.3V PIN74
C13 3.3V PIN76
B13 3.3V PIN78
- - PIN80
Figure 2-10-1 CON Connector on board
Table 2-10-2: Pin Assignment of CON2
FPGA Voltage
PIN Standard
W15 3.3V
W16 3.3V
T14 3.3V
T15 3.3V
- Ground
V13 3.3V
V14 3.3V
W11 3.3V
W12 3.3V
- Ground
Y11 3.3V
Y12 3.3V
V10 3.3V
W10 3.3V
- Ground
AA11 3.3V
AA10 3.3V
AB10 3.3V
NC
NC
NC
NC
CON2 Net
PIN Name
PIN2 B14_L16_P
PIN4 B14_L16_N
PIN6 B13_L14_P
PIN8 B13_L14_N
PIN10 GND
PIN12 B14_L10_P
PIN14 B14_L10_N
PIN16 B14_L8_N
PIN18 B14_L8_P
PIN20 GND
PIN22 B14_L15_N
PIN24 B14_L15_P
PIN26 B14_L17_P
PIN28 B14_L17_N
PIN30 GND
PIN32 B14_L6_N
PIN34 B13_IO0
PIN36 B14_L7_N
