5. QSPI Flash

The board is assembled with 128Mbit of QSPI flash memory using an 4-bit data
bus. The flash device is N25Q128 which uses 3.3V CMOS signaling standard.
Because of its non-volatile property, it is usually used for storing software binaries,
images, sounds or other media. Detail information of QSPI FLASH is shown in table
2-5-1 below:
Part
U8
Pin Assignment of FLASH：
Http://www.heijin.org
16 / 50
IO_L6N_T0_VREF_34
IO_L9N_T1_DQS_34
IO_L9P_T1_DQS_34
IO_L11P_T1_SRCC_34
IO_L12P_T1_MRCC_34
IO_L12N_T1_MRCC_34
IO_L14N_T2_SRCC_34
IO_L15P_T2_DQS_34
IO_L3P_T0_DQS_34
IO_L3N_T0_DQS_34
IO_L14P_T2_SRCC_34
P/N
N25Q128
Table 2-5-1 QSPI Flash Information
Figure 2-5-1 Connections between FPGA and Flash
