Alinx AX7103 FPGA User Manual page 6

HDMI
SiI9134
输出
HDMI
SiI9013
输入
以太网
KSZ9031
网口
以太网
KSZ9031
网口
Judge from the schematic diagram above, the AX7103 Development board could
achieve the below functions.
Artix-7 FPGA Core
The core board consists of XC7A100T+8Gb DDR3+128Mb QSPI FLAS, two high
resolution LVDS differential crystals of Sitime company, one is 200MHz used to
FPGA System， another is 125MHz to provide stable clock input for GTP modules.
PCIe x4 connector
Support PCI Express 2.0 standard，provide PCIe x4 High-speed data transmission
interface, single channel communication speed up to 5GBaud。
10/100M/1000M Ethernet RJ-45 connector
Gigabit Ethernet connector chip, that use KSZ9031RNX Ethernet PHY chip of
Micrel company, provide network communication services for user. Support
10/100/1000 Mbps network transmission rate; Full duplex and adaptive
HDMI Output
SIL9134 HDMI code chip of Silicon Image Company, support up to 1080P@60Hz
output，support 3D output。
HDMI Inupt
SIL9013 HDMI decode chip of Silion Image company，support up to 1080P@60Hz
input，and support date output in different format
USB Uart connector
One Uart transfer to USB connector，that used to communication with computer,
easy to debug. Serial chip USB-UAR of Silicon Labs CP2102GM, MINI USB
connector
Micro SD socket
One Micro SD socket，support SD mode and SPI mode
EEPROM
One chip EEPROM 24LC04 of IIC connector on board
2 pairs of 40-pin expansion header
Http://www.heijin.org
6 / 50
40针IO扩展口
JTAG
125Mhz
XILINX
ARTIX-7
FPGA
核心板
PCIe x 4
40针IO扩展口
QSPI
FLASH
DDR3
DDR3
200Mhz
AX7103 User Manual
SD Card
USB
CP2102
UART
LED*4
按键*2
XADC接
口
