CHAPTER 5 - VIEWING LIBRARY STATUS
U
SING THE
V
IEW
The cartridge inventory graphical view displays library elements, such as slots and
tape drives, with information about the cartridge stored in the element.
• To see the elements organized by module, from Status, navigate to Cartridge
Inventory > Graphical View.
• To see the elements organized by logical library or partition, see
Partition Map Graphical View on
Figure 93 The Cartridge Inventory Graphical View screen.
Moving the mouse over a drive or cartridge to display additional information in a
pop-up window.
Field
Drive Information
Drive
Drive #
JANUARY 2023
C
ARTRIDGE
Description
LTO generation of drive and format (Full Height or
Half Height).
The drive number. Tape drives are numbered from
the bottom of the library up to the top beginning
with "1".
I
NVENTORY
page 158.
156
G
RAPHICAL
Using
SPECTRA STACK LIBRARY
USER GUIDE
