Spectra PowerBox 3000C
Series
USER MANUAL
Version 1.52 – October 2021




Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PowerBox 3000C Series and is the answer not in the manual?

Questions and answers

Related Manuals for Spectra PowerBox 3000C Series

Summary of Contents for Spectra PowerBox 3000C Series

  • Page 1   Spectra PowerBox 3000C Series USER MANUAL Version 1.52 – October 2021      ...

  • Page 2: Table Of Contents

    3.1 Removing the Top Cover ……...……………………………….….…………………..34 3.2 Installing CPU ………………………………………………………………….……………37 3.3 Installing SO-DIMM Memory…………………………………..…………….……………40 3.4 Installing a Mini-PCIe/mSATA Card on Top Side…………………………………..43 3.5 Installing a Mini-PCIe/mSATA Card on Bottom Side……………..…………………...…45 3.6 Installing Antennas…….…….…………..……….…………………………………………..46 Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...
  • Page 3 4.4.1 System Agent (SA) Configuration ……………..……………………………………..84 4.4.2 PCH-IO Configuration ………………….……………………………………………..85 4.5 Security Setup …...……….………………….…..………………..……………………...…88 4.5.1 Administrator Password …….…...……………………………………………………88 4.5.2 User Password …….…………………………………………………..………………88 4.6 Boot Setup …...……….….……………………………...…..….…..………..…………..89 4.7 Save & Exit …...……….….………………….…..….…..………………………....90     Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...
  • Page 4 6.5 Installing a High Speed CMI Module…...…………..……………………………………..115 6.6 Installing a CFM-PoE Module..……….……………………………………………..……..121 6.7 Installing a CFM-IGN Power Ignition Module..……….…………………………………..125 6.8 Installing an External FAN……………………..……….…………………………………..126 6.9 Installing an Internal FAN (For PB-32C only)...…….…………………………………..128 Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 5: Revision

    2021/10/13 Copyright Notice © 2021 by Spectra GmbH & Co. KG. All rights are reserved. No parts of this manual may be copied, modified, or reproduced in any form or by any means for commercial use without the prior written permission of Spectra GmbH & Co. KG. All information and specification provided in this manual are for reference only and remain subject to change without prior notice.

  • Page 6: Declaration Of Conformity

    Product Warranty Statement Warranty Spectra products are warranted by Spectra GmbH & Co. KG to be free from defect in materials and workmanship starting from the date of purchase by the original purchaser. The actual warranty period of Spectra products vary with product categories. During the warranty period, we shall, at our option, either repair or replace any product that proves to be defective under normal operation.
  • Page 7 (such as a fuse, battery, etc.), are not warranted. Before sending your product in, you will need to fill in a Spectra RMA Request Form and obtain a RMA number from us. Please go to www.spectra.de/RMA...

  • Page 8: Technical Support And Assistance

    Technical Support and Assistance 1. Visit the Spectra website at www.spectra.de where you can find the latest information about the product. 2. Contact our technical support team or sales representative for technical support if you need additional assistance. Please have following information ready before you call: ...
  • Page 9 14. CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. 15. Equipment intended only for use in a RESTRICTED ACCESS AREA. Spectra GmbH & Co. KG User Manual sales@spectra.de...

  • Page 10: Package Contents

    Performance, Expandable and Modular Rugged Embedded Computer with 1x PCI/PCIe Expansion Slots 9/8th Generation Intel® Core™ Series Processors, High Spectra Performance, Expandable and Modular Rugged Embedded PowerBox 32C* Computer with 2x PCI/PCIe Expansion Slots Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 11: Chapter 1 Product Introductions

    Chapter 1 Product Introductions Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 12: Overview

    1.1 Overview Spectra PowerBox 3000C series is a high performance fanless embedded computer, powered by generation Intel® Core™ processor (Coffee Lake) with up to 8 cores and 64 GB DDR4 memory capacity for unprecedented performance to fulfill all kinds of high-end computing requirements.

  • Page 13: Product Pictures

    4x CMI Slots for Modular I/O Expansions   1x CFM Slot for Power Ignition Sensing Function  Wide Operating Temperature (-40°C to 70°C)  EN50155 (EN50121-3-2) / EN62368-1 Certified Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 14: Hardware Specification

    - Intel® Core™ i5-8500T 6 Cores Up to 3.5 GHz - 9M Cache, TDP 35W Spectra PowerBox 30C : 227 x 261 x 88 mm, 4.3 kg - Intel® Core™ i3-8100T 4 Cores 3.1 GHz - 6M Cache, TDP 35W Spectra PowerBox 31C: 227 x 261 x 108 mm, 4.92 kg...

  • Page 15: System I/O

    Used to inserts a SIM card, CMOS battery, and Digital I/O LED 2.5” HDD Indicates the working status of digital input/ output Spectra PowerBox 30C*                    Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...
  • Page 16 Spectra PowerBox 31C* Spectra PowerBox 32C*   Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 17: Rear

    A terminal block used to connect to remote USB 3.0 Port power on/off switch Used to connect USB 3.0/2.0/1.1 device Universal I/O Bracket Used to customized I/O output Spectra PowerBox 30C*   Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...
  • Page 18 Spectra PowerBox 31C*   Spectra PowerBox 32C*   Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 19: Mechanical Dimension

    Spectra PowerBox 30C*                                                                                 ...
  • Page 20 Spectra PowerBox 32C*                                                                                 ...
  • Page 21 Chapter 2 Switches & Connectors Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 22: Location Of Switches And Connectors

    2.1 Location of Switches and Connectors 2.1.1 Top View   Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 23: Bottom View

    2.1.2 Bottom View   Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 24: Switches And Connectors Definition

    CN3, CN4 Mini PCI-Express / mSATA Socket M.2 PCIE / SATA SSD USB2_13_1 Internal USB 2.0 Ports PCIE1 PCI-Express X1 Socket PCIE2 PCI-Express X16 Socket SODIMM1, SODIMM2 DDR4 SODIMM Socket Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 25: Definition Of Switches

    Enable (Default) COM1/2 Voltage Function Setting: Pin Define SW1 Switch Switch Function mode     0V(RI) ON/ON (Default) COM1 ON/OFF OFF/OFF     0V(RI) ON/ON (Default) COM2 ON/OFF OFF/OFF Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 26: Definition Of Connectors

    47 NA 12 SIM_CLK SMB_CLK 48 +1.5V PETN/SATATN 49 NA REFCLK+/SIM_PWR2 14 SIM_Reset1 SMB_DATA 50 GND 15 GND PETP/SATAPN 51 NA 16 SIM_VPP1 52 +3.3V 17 SIM_CLK2 18 GND USB_D- Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...
  • Page 27 12 NA SMB_CLK 48 +1.5V 13 NA PETN/SATATXN 49 NA 14 NA SMB_DATA 50 GND 15 GND PETP/SATATXP 51 NA 16 NA 52 +3.3V 17 NA 18 GND USB_D- Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...
  • Page 28 12 NA SMB_CLK 48 +1.5V 13 REFCLK+ PETN/SATATN 49 NA 14 NA SMB_DATA 50 GND 15 GND PETP/SATATP 51 NA 16 NA 52 +3.3V 17 NA 18 GND USB_D- Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...
  • Page 29 PEDET 18 +3.3V ALERT# +3.3V 19 PERP2 20 NC +3.3V 21 CFG0 PETN0/SATATN0 73 22 NC +3.3V 23 PETN2 PETP0/SATATP0 75 CFG2 24 NC RESET# 25 PETP2 26 NC Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...
  • Page 30 1    +12V CLR_CMOS1: Clear BIOS Switch Definition 1-2 (Left) Normal Status (Default) 2-3 (Right) Clear BIOS PWR_SW1: Power on/ off switch and Thermal LED Button Definition Green Blue Thermal Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...
  • Page 31 DC power connector to system. FAN1: External PWM Fan Connector Connector Type: Terminal Block 1X4 4-pin, 3.5mm pitch Definition 1 2 3   +12V SENSE Control Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...
  • Page 32 DC_IN1: 4 PINs DC 9~48V Power Connector Connector Type: 2x2 4-pin, 4.2mm pitch  Definition +9~48VIN +9~48VIN Before using this connector, make sure that the PIN3 & PIN4 voltage meets the power requirements of the device. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 33: Chapter 3 System Setup

    Chapter 3 System Setup Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 34: Removing The Top Cover

    1. Turn over the unit to have the bottom side face up, loosen the 6 screws on the bottom cover and place them aside for later use. 2. Remove the bottom cover from the chassis. Spectra GmbH & Co. KG User Manual sales@spectra.de...
  • Page 35 3. Unscrew the 2 screws at rear panel as marked on the photo and place them aside for later use. 4. Loosen the 4 screws. Pull out 4 latches as marked on the photo. Spectra GmbH & Co. KG User Manual sales@spectra.de...
  • Page 36 5. Lift up the unit vertically by holding the front and rear panel. 6. Turn over the body of the unit and place it gently. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 37: Installing Cpu

    Locate the CPU socket, remove the protection cover on it. Press the CPU socket lever and pull it aside away from the socket to unlock it. Pull back the lever to open the socket. Spectra GmbH & Co. KG User Manual sales@spectra.de...
  • Page 38 Align the notches on CPU with the alignment post on socket. The notches of socket provide the space for fingers while lowering the CPU, hold the CPU by the edges toward the notches and insert the CPU gently. Spectra GmbH & Co. KG User Manual sales@spectra.de...
  • Page 39 Place the thermal pad on the CPU heat spreader. Press down the socket lever to lock the CPU.  Align mounting holes of heatsink with the nut studs and fasten the heat sink with provided 4 screws.   Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 40: Installing So-Dimm Memory

    3.3 Installing SO-DIMM Memory 1. Locate the SO-DIMM sockets at the bottom side of system. Unscrews the 4 screws and remove the bracket. 2. Locate two SO-DIMM sockets at the bottom. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...
  • Page 41 45° 45°     Upper socket  Lower socket  4. Press the modules down until it’s fixed firmly by the two locking latches on the sides. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...
  • Page 42 5. Put the cover back and fix the cover with 4 screws. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 43: Installing A Mini-Pcie/Msata Card On Top Side

    Use provided two screws fasten the half size module and adapter bracket together as shown in Fig (a) below. (b) Full Size Mini-PCIe Card  (a) Half Size Mini-PCIe Card  Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...
  • Page 44 Insert the Mini-PCIe card at a 45-degree angle until its edge connector is connected firmly into slot. 45°   Press down the module and fasten two screws to secure the module. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 45: Installing A Mini-Pcie/Msata Card On Bottom Side

    1. Turn over the body of the unit. Locate Mini-PCIe (mSATA) slots at the bottom. 2. Tilt the Mini-PCIe module at a 45-degree angle and insert it to the slot until the gold-pated connector of module contacted firmly with the slot. 45°   Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 46: Installing Antennas

    3. Press down the module and use previous two screws to fix the module. 3.6 Installing Antennas 1. Remove the antenna rubber covers on rear panel. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...
  • Page 47 2. Have antenna jack penetrate through the hole. 3. Put on washer and fasten the nut with antenna jack. 4. Assemble the antenna and antenna jack together. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...
  • Page 48 5. Attach the RF connector at another end of cable onto the module. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 49: Installing A Sata Hard Drive On Top Side

    2. Make the PCB side of the HDD face up, place the HDD bracket on it. Ensure the direction of bracket is correct and use 4 provided screws to assemble HDD and HDD bracket together. Spectra GmbH & Co. KG User Manual sales@spectra.de...
  • Page 50 3. Turn over the HDD bracket. Connect the HDD bracket to the SATA connector and fasten the 3 screws. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 51: Installing An M.2 Card

    3.8 Installing an M.2 Card 1. Turn over the body of the unit. Unscrew the 2 screws and remove the bracket. Locate M.2 slots at the bottom. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...
  • Page 52 3. Tilt the M.2 M Key card at a 45-degree angle and insert it to the slot until the gold-pated connector of module contacted firmly with the slot. 45°   4. Press down the module and use previous one screw to fix the module. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 53: Installing A Pci/Pcie Add-On Card

    3.9 Installing a PCI/PCIe Add-on Card (For PB31C and PB32C only) The applicable riser cards for Spectra PowerBox 3000C series are listed in the following table. Model No. Description Compatible Model RSC-E16 Riser Card 1 x PCIex16 PowerBox 31C RSC-PI-01...
  • Page 54 2. Unscrew the 4 screws to remove the extension bracket. 3. Remove the extension bracket from the system. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...
  • Page 55 4. Assemble the riser card with extension bracket together and fasten with the 4 screws. 5. (1) Loosen the screw to remove I/O bracket. (2) Loosen the 2 screws halfway to allow the card retainer to be adjustable. Spectra GmbH & Co. KG User Manual sales@spectra.de...
  • Page 56 (4) Tighten the screw to fix the card retainer. 7. Locate the riser card slot on bottom side of system. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...
  • Page 57 8. Install the module assembled in step 4 into the riser card slot, and fasten the 4 screws to secure it. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 58: Assembling The System

    1. Make sure the notch on chassis and the front bezel of body are at the same side. 2. Lift up the body of unit. Make sure that both front and rear panels are in the chassis groves and assemble the body on to chassis firmly. Spectra GmbH & Co. KG User Manual sales@spectra.de...
  • Page 59 3. Push into the 4 latches as indicated and fasten the 4 screws. 4. Fasten the 2 screws at rear panel. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...
  • Page 60 5. Be sure to align the grooves with front and rear panels. Put the cover back on and fasten the 6 screws to fix the cover. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 61: Installing A Sata Hard Drive At Front Side

    3.11 Installing a SATA Hard Drive at Front Side 1. Loosen the screws in order to remove the front expansion plate. 2. Locate the removable HDD bay and loosen the screw. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...
  • Page 62 4. Make the PCB side of the HDD face up, place the HDD bracket into it. Ensure the direction of bracket is correct and use 4 provided screws to assemble HDD and HDD bracket together. Spectra GmbH & Co. KG User Manual sales@spectra.de...
  • Page 63 5. Align the HDD bracket with the entrance of HDD bay. Holding the rotating arm and insert the HDD bracket until the connector of HDD contact the SATA connector firmly. 6. Place the rotating arm back and fasten the screw. Spectra GmbH & Co. KG User Manual sales@spectra.de...

  • Page 64: Installing A Sim Card

    3.12 Installing a SIM Card 1. Locate the SIM card slot at front side. 2. Insert the SIM card according to the icon instruction aside. SIM 1  SIM 2  Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 65: Installing The Cmos Battery

    3.13 Installing the CMOS Battery 1. Locate the removable CMOS Battery and loosen the screw. 2. Pull out the CMOS battery bracket with assistance of a tweezer. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...
  • Page 66 3. Insert a CMOS battery in the battery slot. 4. Insert the battery bracket firmly and fasten the screw. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 67: Fastening The Cover

    3.14 Fastening the Cover 1. Fasten the cover by using the two screws. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 68: Wall Mount Brackets

    3.15 Wall Mount Brackets Spectra PowerBox 3000C series offers wall mount that customers can install system on the wall in convenient and economical ways. 1. The mounting holes are at the bottom side of the system. Use the provided 8 screws to fasten the bracket and the system together.
  • Page 69 2. Fasten the screws through the bracket mounting hole to mount system on the wall. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 70: Chapter 4 Bios Setup

    Chapter 4 BIOS Setup Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 71: Bios Introduction

    Then you can use the control keys to enter values and move from field to field within a sub-menu. If you want to return to the main menu, just press the <Esc >. Spectra GmbH & Co. KG User Manual sales@spectra.de...

  • Page 72: Main Setup

    4.2.1 System Date Set the date. Please use <Tab> to switch between date elements. 4.2.2 System Time Set the time. Please use <Tab> to switch between time elements. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 73: Advanced Setup

    Enables or disables Intel (VMX) Virtualization Technology. Virtualization enhanced by Intel Virtualization Technology will allow a platform to run multiple operating systems and applications in independent partitions. With virtualization, one computer system can function as multiple virtual systems. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 74: Sata Configuration

    Enables or disables SATA Port 0. ■ Serial ATA Port 1  Port 1 [Enabled] Enables or disables SATA Port 1. ■ Serial ATA Port 2  Port 2 [Enabled] Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 75: Pch-Fw Configuration

    Enables or disables SATA Port 5. 4.3.3 PCH-FW Configuration ■ Firmware Update Configuration Configure Management Engine Parameters  Me FW Image Re-Flash [Disabled] Enables or disables Me FW Image Re-Flash function. 4.3.4 Trusted Computing Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...
  • Page 76 Enables or disables storage hierarchy. ■ Endorsement Hierarchy [Enabled] Enables or disables endorsement hierarchy. ■ Physical Presence Spec Version [1.3] Select the physical presence spec version. Configuration options: [1.2] [1.3] Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 77: Acpi Settings

    Allows users to select the highest Advanced Configuration Power Interface® (ACPI) sleep state that system will enter when suspend button is pressed. [Suspend Disabled]: Disables entering suspend state. [S3 (suspend to RAM)]: Enables suspend to RAM state. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 78: F81866 Super Io Configuration

    Allows you to change the IO Address & IRQ settings of the specified serial port.  Onboard Serial Port 1~6 Mode [RS232] Allows you to select Serial Port Mode. Configuration options: [RS232] [RS422/RS485 Full Duplex] [RS485 Half Duplex] Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 79: Hardware Monitor

    Allows users to setting external smart fan parameters. ■ Internal Smart Fan Function [Enabled] Enables or disables internal smart fan function. ■ Internal Smart Fan Configuration Allows users to setting internal smart fan parameters. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 80: S5 Rtc Wake Settings

    [Dynamic Time]: Sets an increase minute(s) from current time to wake system from S5. 4.3.9 Serial Port Console Redirection ■ Console Redirection Allow users to enable or disable COM0, COM1, COM2, COM3, COM4, COM5 console redirection function. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 81: Usb Configuration

    Enables or disables XHCI (USB3.0) hand-off function. Use this feature as a workaround for operating systems without XHCI hand-off support. ■ USB Mass Storage Driver Support [Enabled] Enables or disables USB mass storage driver support. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 82: Network Stack Configuration

    [UEFI and Legacy]: Allows booting from operating systems that support legacy option ROM or UEFI option ROM. [Legacy only]: Allows booting from operating systems that only support legacy option ROM. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 83: Nvme Configuration

    ■ Other PCI devices [Do not launch] Allows users to determine option ROM execution policy for devise other than network, storage, or video. 4.3.13 NVMe Configuration This screen displays the current NVMe device information. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 84: Chipset Setup

    This feature sets the maximum TOLUD (Top of Low Usable DRAM) value, which specifies the TOLUD memory space to be used by internal graphics devices, GTT Stolen Memory, and TSEG, respectively, if these devices are enabled. Spectra GmbH & Co. KG User Manual sales@spectra.de...

  • Page 85: Pch-Io Configuration

    Allows users to enable or disable Internal Graphics. Configuration options: [Auto] [Disabled] [Enabled] ■ VT-d [Enabled] Enables or disables Intel® Virtualization Technology for Directed I/O (VT-d) capability. 4.4.2 PCH-IO Configuration Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...
  • Page 86  PCI Express Root Port 1 [Enabled] Enables or disables PCI Express Root Port 1.  PCIeSpeed [Auto] Allows you to select PCI Express port speed. Configuration options: [Auto] [Gen1] [Gen2] [Gen3]. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...
  • Page 87 ■ Power Failure [Keep last state] Allows you to specify which power state system will enter when power is resumed after a power failure (G3 state). [Always on]: Enters to power on state. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 88: Security Setup

    4.5.1 Administrator Password Administrator Password controls access to the BIOS Setup utility. 4.5.2 User Password User Password controls access to the system at boot and to the BIOS Setup utility. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 89: Boot Setup

    ■ Hard Drive BBS Priority Allows you to set the order of the legacy devices in this group. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 90: Save & Exit

    This item allows you to save the changes done so far as user defaults. ■ Restore User Defaults This item allows you to restore the user defaults to all the setup options. Spectra GmbH & Co. KG User Manual sales@spectra.de...

  • Page 91: Chapter 5 Product Application (For Dio Only)

    Chapter 5 Product Application (For PB-3000C-DIO only) Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 92: Digital I/O (Dio) Application

    GPIO33 (PIN 39) GPIO43 (PIN 47) GPIO34 (PIN 40) GPIO44 (PIN 48) GPIO35 (PIN 41) GPIO45 (PIN 49) GPIO36 (PIN 42) GPIO46 (PIN 50) GPIO37 (PIN 43) GPIO47 (PIN 51) Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...
  • Page 93 Following is an example to enable configuration and to disable configuration by using debug. -o 4e 87 -o 4e 87 (enable configuration) -o 4e aa (disable configuration) 5.1.1.4 Relative Registers To program the F81866A configuration registers, see the following configuration procedures. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...
  • Page 94 Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...
  • Page 95 Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...
  • Page 96 Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...
  • Page 97 // Set GP80 to GP87 output Mode WriteByte(AddrPort, 0x88) // Select configuration register 88h WriteByte(DataPort, 0xXF)) // Set (bit 0~7) = 1 to select GP 80 ~87 as Output mode. <Output Value> Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...
  • Page 98 // Read bit 0~7(0xFx)= GP70~77 as High <input Value> WriteByte(AddrPort, 0xC2) // Select configuration register C2h ReadByte(DataPort, Value) // Read bit 0~7(0xFx)= GP30~37 as High <Leave the Extended Function Mode> WriteByte(AddrPort, 0xAA) Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...
  • Page 99 <Enter the Extended Function Mode> WriteByte(AddrPort, 0x87) WriteByte(AddrPort, 0x87) // Must write twice to enter Extended mode <Select Logic Device> WriteByte(AddrPort, 0x07) WriteByte(dataPort, 0x06) // Select logic device 06h Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...
  • Page 100 // Select configuration register 60h (High Byte address) WriteByte(DataPort, (0x0A)) WriteByte(AddrPort, 0x61) // Select configuration register 61h (Low Byte address) WriteByte(DataPort, (0x00)) <Leave the Extended Function Mode> WriteByte(AddrPort, 0xAA) default GPIO Port base address is 0xA00h Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...
  • Page 101 +3) +2) (0xA02) (0xA03) = DI7 = DO7 (Base Base address address +3) +2) (0xA02) (0xA03) = DI8 = DO8 (Base Base address address +3) +2) (0xA02) (0xA03) Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...
  • Page 102 +9) +10) (0xA10) (0xA09) = DI15 = DO15 (Base Base address address +9) +10) (0xA10) (0xA09) = DI16 = DO16 (Base Base address address +9) +10) (0xA10) (0xA09) Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...
  • Page 103 DI13 DI12 DI11 DI10 Data Bits Digital Input I/O Port Address 0xA09 Pin Definition DO16 DO15 DO14 DO13 DO12 DO11 DO10 Data Bits Digital Output I/O Port Address 0xA010 Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 104: Digital I/O (Dio) Hardware Specification

      Signal High Level: Pull up resistor to XCOM+ ‐   Signal Low Level: = XCOM- ‐   Sink Current: 1A (Max) ‐   Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 105: Dio Connector Definition

    DIO1: Digital Input / Output Connector Connector Type: Terminal Block 2X5 10-pin, 3.5mm pitch Definition Definition XCOM+ XCOM- (DC INPUT) (GND) Definition Definition 2XCOM+ 2XCOM- (DC INPUT) (GND) Reference Input Circuit Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...
  • Page 106 (DI10) (DO10) (DI11) (DO11) (DI12) (DO12) XCOM+ XCOM- (DC INPUT) (GND) Definition Definition (DI13) (DO13) (DI14) (DO14) (DI15) (DO15) (DI16) (DO16) 2XCOM+ 2XCOM- (DC INPUT) (GND) Reference Output Circuit Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 107: Chapter 6 Optional Modules Pin Definitions And Settings

    Chapter 6 Optional Modules Pin Definitions and Settings Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 108: Cmi-Com Connector Definition And Settings

    COM3~COM6 Voltage Function Setting: Pin Define SW1 Switch Function Definition 0V(RI) ON/ON (Default) COM3 ON/OFF OFF/OFF 0V(RI) ON/ON (Default) COM4 ON/OFF OFF/OFF 0V(RI) ON/ON (Default) COM5 ON/OFF OFF/OFF 0V(RI) ON/ON (Default) COM6 ON/OFF OFF/OFF Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...
  • Page 109 PB-3000C-iCOM: COM3~COM6: RS232 Connector, Connector Type: 9-pin D-Sub RS232 Definition COM3/4/5/6 are isolated COM, each pin5 (GND) is independent.  Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 110: Cmi-M12 Connector Definition And Settings

    Connector Type: M12 A coded 8pin connector Definition Definition 2_LAN1_0+ 2_LAN1_0- 2_LAN1_1+ 2_LAN1_2+ 2_LAN1_2- 2_LAN1_1- 2_LAN1_3+ 2_LAN1_3- PB-3000C-LAN-xM12 Module Pin Definitions Connector Type: M12 X coded 8pin connector Definition Definition Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 111: Cmi-Ign Connector Definition And Settings

    1 hour (IGN 2 hours Enabled) Reserved (0 second) 24V_12V_1: 12V / 24V Car Battery Switch Definition 1-2 (Right) 24V Car Battery Input 2-3 (Left) 12V Car Battery Input Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 112: Installing A Low Speed Cmi Module

    6.4 Installing a Low Speed CMI Module The applicable low speed CMI modules for Spectra PowerBox 3000C series are listed in the following table. Model No. Product Description PB-3000C-COM CMI Module with 4x RS232/422/485 Serial Ports, 1x Universal Bracket with 4x DB9 Cutout...
  • Page 113 2. Locate the connector of CMI-module on the top side of system. 3. Insert the CMI module carefully into the CMI connector on the main board. Fix it with 4 screws. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...
  • Page 114 4. Fasten the 2 hex nuts from the back side of front bezel. 5. Fasten the 8 D-Sub jack screws as marked on photo. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 115: Installing A High Speed Cmi Module

    6.5 Installing a High Speed CMI Module   The applicable high speed CMI modules for Spectra PowerBox 3000C series are PB-3000C-LAN, PB-300C-LAN-M12 and PB-3000C-LAN-xM12 6.5.1 PB-3000C-LAN-M12 Module 1. Loosen the 2 hex nuts from back side of front bezel. Remove the front bezel.
  • Page 116 3. Remove the 4 ring nuts from M12 jack before attempting to install the module. 4. Insert the CMI module vertically into the female connector on system’s mainboard until it’s connected firmly and fasten 4 screws to fix it. Spectra GmbH & Co. KG User Manual sales@spectra.de...
  • Page 117 5. Attach the M12 I/O bracket. 6. Fasten 2 hex nuts from the back side of the bracket. 7. Fasten the 4 ring nuts onto M12 jacks. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...
  • Page 118   1. Assemble the hex rings, M12 I/O bracket and hex washers together as indicated below: Penetrate hex rings through the M12 I/O bracket holes, and fix them with hex washers. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...
  • Page 119 3. Locate the connector of CMI module on top side of system. 4. Insert the CMI module vertically into the female connector on system’s mainboard until it’s connected firmly and fasten 4 screws to fix it. Spectra GmbH & Co. KG User Manual sales@spectra.de...
  • Page 120 5. Attach the assembled M12 I/O bracket on to the system, and fasten the hex nuts to fix it. 6. Put on the rubber rings to the four M12 LAN ports. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 121: Installing A Cfm-Poe Module

    (Please don’t block the LED.) 1. Insert the CMI module vertically into the female connector on system’s mainboard until it’s connected firmly and fasten 4 copper pillars to fix it. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...
  • Page 122 4. Please paste the 2 thermal pads onto the heatsink carefully. Before putting on the heatsink (in the step 6), please make sure the protective films on the Thermal Pads have been removed!  Spectra GmbH & Co. KG User Manual sales@spectra.de...
  • Page 123 Before putting on the heatsink (in the step 6), please make sure the protective film on the Thermal Pad has been removed!  6. Please paste the heatsink onto the CFM-PoE module carefully. 7. Fasten 4 screws to fix it. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...
  • Page 124 8. Please paste the thermal pad onto the heatsink carefully. Note: Before assembling the system’s chassis cover, please make sure the protective film on the Thermal Pad has been removed!  Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 125: Installing A Cfm-Ign Power Ignition Module

    6.7 Installing a CFM-IGN Power Ignition Module 1. Locate power ignition connector on main board. 2. Insert the power ignition module carefully into the connector on main board. Fasten 2 screws to fix it. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 126: Installing An External Fan

    2. Slide the FAN into the middle groove of chassis as illustrated. Tighten the 2 screws to fix it onto chassis. 3. Move the fan to the center of chassis. Tighten the 2 screws marked on photo to secure it. Spectra GmbH & Co. KG User Manual sales@spectra.de...
  • Page 127 4. Connect the FAN cable to external fan power connector at rear panel. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...

  • Page 128: Installing An Internal Fan (For Pb32C Only)

    Inhaling Fan with 4pin Connector, Universal Bracket 1. Unscrew 6 screws to remove 3 I/O brackets from rear panel. 2. Attach the FAN from back side of rear panel. Fasten 4 screws to fix it. Spectra GmbH & Co. KG User Manual sales@spectra.de...
  • Page 129 3. Connect the FAN power cable to the power connector on main board.as marked on photo. Spectra GmbH & Co. KG User Manual sales@spectra.de Spectra PowerBox 3000C...
  • Page 130   Spectra GmbH & Co. KG Spectra GmbH & Co. KG Spectra (Schweiz) AG Spectra GmbH & Co. KG Mahdenstr. 3 Gewerbepark Ost 1 Flugplatzstr. 5 Mahdenstr. 3 72768 Reutlingen 4621 Sipbachzell (Wels) 8404 Winterthur 72768 Reutlingen Germany Austria Switzerland...

Table of Contents
