11. Type the address for your backup DNS server, or press E
the default address of 0.0.0.0 if you do not have one. When you press
E , a screen similar to the following one appears that shows your
NTER
new network defaults and presents you with the System Defaults Setup
menu:
Default Gateway (-(previous), q(uit), <192.168.4.1>):
Subnet Mask (-(previous), q(uit), <255.255.255.0>):
Primary DNS Server (-(previous), q(uit), <192.168.11.251>):
Backup DNS Server (-(previous), q(uit), <0.0.0.0>):
System Defaults Setup
1. Network Defaults
2. Ras Defaults (Required)
3. Ras Security Defaults (Required)
4. T1 Defaults (Required)
5. E1 Defaults (Required)
6. PRI Defaults (Required)
Enter Selection
12. When you press E
NTER
Frame Type
1. TYPE_II
2. SNAP
Enter Selection
13. Type the number of the frame type used by your network, or press
E to accept the default. TYPE_II is the standard Ethernet frame
NTER
type. SNAP is supported only by some older UNIX systems. When you
press E , the following menu appears:
NTER
Address Method
1. via DHCP server
2. Address pool
3. Per port config
4. RADIUS
Enter Selection
14. Use the Address Method menu to specify how IP addresses will be
allocated to the remote users. Select via DHCP server if you have a
DHCP server on your LAN. Select Address pool if the IP addresses you
assign to the clients are continuous. Select Per port config if you want to
assign a specific address to each remote port. Select RADIUS if you want
to use your RADIUS server to assign IP addresses. Type the number of
the address allocation method you want the RAS to use, or press E
to accept the default. When you press E
appears:
Wan Port IPCP
1. Disabled
2. Enabled
Enter Selection
2 Configuration Quick Start
(-(previous), q(uit), <2>):
, the following menu appears:
(-(previous), q(uit), <1>):
(-(previous), q(uit), <3>):
NTER
(-(previous), q(uit), <1>):
to accept
NTER
2
NTER
, the following menu
