71. At the Config Ras option, type y and press E
72. To configure another RASCard, type the device number of the RASCard
PRI Card(s) Setup
Note: Before you begin the configuration procedures, please verify that all T1
cables and/or PRI cables are connected to their respective telco lines. For
information on telco line setup, contact you telco.
Note: as you configure the PRI Card(s), make note of your settings on the
Site Planning sheet.
73. The Device Specific Setup menu reappears:
6. Frame Type:TYPE_II

7. Address Method:Address pool

8. Address Pool Start:192.168.90.230
9. Address Pool End:192.168.90.253

10.Start 1st Exclusion:0.0.0.0

11.End 1st Exclusion:0.0.0.0

12.Start 2nd Exclusion:0.0.0.0
13.End 2nd Exclusion:0.0.0.0

14.RAS Express Password:********

15.Protocol:Local

16.Primary Server:192.168.90.1

17.Secondary Server:0.0.0.0

18.Shared Secret Password:********

Config Ras? (<y>, n): y
The following messages appear:
Configuring ...
Config Completed
The RAS Card must be reset to finish the config.
RAS? (<y>, n):
Type y and ENTER to reset the card. The Select a Ras card menu apears:
Select a RAS Card (1A,<5A>,9A,13A, -(previous), d(one)):
you want to set up, and repeat steps 45-71. Otherwise, type d (one) and
press E to finish.
NTER
Note: Look for error messages such as "Timeout Waiting for Responses"
or Not Enough IP Addresses." If errors are encountered, refer to the
FAQ and Troubleshooting section of your documentation set.
Device Specific Setup
1. Controller Setup
2. Ras Setup
3. T1 Setup (Required)
4. E1 Setup (Required)
5. PRI Setup (Required)
Enter Selection (-(previous), q(uit), <5>):
Note: Although both option 3, T1 Setup, 4, E1 Setup and option 5, PRI
Setup, are listed as required, you will only need to configure the option
that matches your segment type.
2 Configuration Quick Start
to save your changes.
NTER
Reset the
5
81
