1. Use Active Settings (pre-configured card)
2. Use System Defaults (new card)
3. Use Stored Settings (swapping cards)
Enter Selection (q(uit), ,1>: 1
57. Type 1 to use settings from a pre-configured card. Type 2 to use the
System default for a new card. Type 3 to swap a card using stored
settings. Press ENTER.
58. A configuration summary for the PRI card appears, followed by the
Switch Type menu:
Getting PRI Info ..
1. Switch Type:Net 5 (Euro ISDN)
2. Error Correction (CRC4/6):Enabled
3. Call Distribution:One to One
4. Set Carrier:PCM30/CEPT
5. Active Channels:30
Enter Selection
59. Verify that the European ISDN has been selected. Verify the correct
Error correction, call distribution, set carrier and active channels have
been set for your configuration. If you need to change a value, type the
menu option number and ENTER. When all values have been changed,
type d and ENTER.
60. A configuration summary appears:
Switch Type: Net 5 (Euro ISDN)
Error Correction (CRC4/6):Enabled
Call Distribution:One to One
Set Carrier:PCM24/T1
Active Channels:30
Save changes and config the device? (<y>, n): y
61. Type y to save the changes and configure the PRI card. The following
messages appear:
Configuring . . . .
Config completed
The RAS must be reset to finish the PRI config.
RAS? (<y>, n): y
Select a PRI Card (2A, -(previous), <d>(one)):
62. To configure another PRI card, type the device number of the PRI you
want to set up, and repeat steps 60-66. Otherwise, type d and press
E to finish. The Device Specific Setup menu appears:
NTER
Device Specific Setup
1. Controller Setup
2. Ras Setup
3. T1 Setup
4. E1 Setup
5. PRI Setup
Enter Selection (-(previous), q(uit), <4>):
Type q and ENTER. The Save System Defaults message appears:
Save System Defaults? (<y>, n):
63. Type y and E to save the defaults. The following message appears:
NTER
2 Configuration Quick Start
(-(previous), q(uit), d(one) <5>):
Reset the
d
