System Installation and Quick Start Guide
75. Type the shared secret password used by your security server and press
76. When you finish configuring the port addresses, a summary of the
77. At the Config Ras option, type y and press E
78. To configure another RASCard, type the device number of the RASCard
79. The Device Specific Setup menu appears:
64
Shared Secret Password (-(previous), q(uit), <********):
E , or just press E
NTER NTER
string to confirm that you typed it correctly, and press E
RASCard configuration appears:
1. IP Address:192.168.90.4
2. Subnet Mask:255.255.255.0
3. Default Gateway:192.168.90.1
4. Primary DNS Server:192.168.90.1
5. Backup DNS Server:0.0.0.0
6. Frame Type:TYPE_II
7. Address Method:Address pool
8. Address Pool Start:192.168.90.230
9. Address Pool End:192.168.90.253
10.Start 1st Exclusion:0.0.0.0
11.End 1st Exclusion:0.0.0.0
12.Start 2nd Exclusion:0.0.0.0
13.End 2nd Exclusion:0.0.0.0
14.RAS Express Password:********
15.Protocol:Local
16.Primary Server:192.168.90.1
17.Secondary Server:0.0.0.0
18.Shared Secret Password:********
Config Ras? (<y>, n): y
The following messages appear:
Configuring ...
Config Completed
The RAS must be reset to finish the config.
RAS? (<y>, n): y
Select a RAS Card (1A,<5A>,9A,13A, -(previous), d(one)):
d
you want to set up, and repeat steps51-77. Otherwise, type d (one) and
press E to finish.
NTER
Note: Look for error messages such as "Timeout Waiting for Responses"
or Not Enough IP Addresses." If errors are encountered, refer to the
FAQ and Troubleshooting section of your documentation set.
Device Specific Setup
1. Controller Setup
2. Ras Setup
3. T1 Setup (Required)
4. E1 Setup (Required)
5. PRI Setup (Required)
Enter Selection (-(previous), q(uit), <3>):
to accept the current password. Retype the
to save your changes.
NTER
again.
NTER
Reset the
