Multitech CommPlete CC2400 System Installation And Quick Start Manual page 41

RASCard Setup
49. Verify that all RASCards are turned on. Type 2 and press E
50. Type the device number of the RASCard you want to set up and press
51. Type 1 or press E
52. Verify the settings for each option. To change a value, type the number
2. Ras Setup
3. T1 Setup (Required)
4. E1 Setup (Required)
5. PRI Setup (Required)
Enter Selection (-(previous), q(uit), <2>):
Note: as you configure the RASCard, make note of your settings on the
T1 Site Information sheet.
the RASCards. The following line appears:
Select a Ras Card (1A, 5A, 9A, 13A, -(previous), <d>(one)):
5A
E . Valid device numbers are listed in the option line. The Use
NTER
Settings From menu appears:
Use settings from:
1. Use Active Settings (pre-configured card)
2. Use System Defaults (new card)
Enter Selection (q(uit), <1>:
if you want to use or modify the settings stored in
NTER
the currently selected RASCard. Type 2 if you want to use or modify the
default RAS settings. The controller displays a screen similar to the
following with the options displayed varying based on the Address
Method selected:
Getting Ras Info ......
1. IP Address
2. Subnet Mask
3. Default Gateway
4. Primary DNS Server
5. Backup DNS Server
6. Frame Type
7. Address Method
8. Address Pool Start
9. Address Pool End
s t
10.Start 1 Exclusion
st
11.End 1 Exclusion
n d
12.Start 2 Exclusion
nd
13.End 2 Exclusion
14.RAS Express Password
15.Protocol
16.Primary Server
17.Secondary Server
18.Shared Secret Password
Enter Selection (-(previous), q(uit), d(one), <1>: 2
corresponding to menu item.
2 Configuration Quick Start
2
NTER
:192.168.4.151
:255.255.255.0
:192.168.4.1
:0.0.0.0
:0.0.0.0
:TYPE_II
:Address pool
:192.168.4.200
:192.168.4.247
:0.0.0.0
:0.0.0.0
:0.0.0.0
:0.0.0.0
:********
:Local
:0.0.0.0
:0.0.0.0
:********
to set up
