System Installation and Quick Start Guide
RASCard(s) Setup
44. Verify that all RASCards are turned on. Type 2 and press E
45. Type the device number of the RASCard you want to set up and press
46. Type 1 or press E
47. Verify the settings for each option. To change a value, type the item
48. To change the IP Address, type 1 and ENTER. The IP Address option
76
4. E1 Setup (Required)
5. PRI Setup (Required)
Enter Selection (-(previous), q(uit), <2>):
Note: as you configure the RASCard, make note of your settings on the
PRI Site Information sheet.
the RASCards. The following line appears:
Select a Ras Card (1A, 5A, 9A, 13A, -(previous), <d>(one)):
5A
E . Valid device numbers are listed in the option line. The Use
NTER
Settings From menu appears:
1. Use Active Settings (pre-configured card)
2. Use System Defaults (new card)
3. User Stored Settings (swapping cards)
Enter Selection (q(uit), <1>:
if you want to use or modify the settings stored in
NTER
the currently selected RASCard. Type 2 if you want to use or modify the
default RAS settings configured earlier. Type 3 if you want to use stored
settings. The controller displays a screen similar to the following:
Getting Ras Info ......
1. IP Address
2. Subnet Mask
3. Default Gateway
4. Primary DNS Server
5. Backup DNS Server
6. Frame Type
7. Address Method
8. Address Pool Start
9. Address Pool End
s t
10.Start 1 Exclusion
st
11.End 1 Exclusion
n d
12.Start 2 Exclusion
nd
13.End 2 Exclusion
14.RAS Express Password
15.Protocol
16.Primary Server
17.Secondary Server
18.Shared Secret Password
Enter Selection (-(previous), q(uit), d(one), <1>: 2
number of the value you would like to change.
When you have completed all the necessary changes, type d and
ENTER. Proceed to RASCard Setup step # 70.
appears:
NTER
:192.168.4.151
:255.255.255.0
:192.168.4.1
:0.0.0.0
:0.0.0.0
:TYPE_II
:Address pool
:192.168.4.200
:192.168.4.247
:0.0.0.0
:0.0.0.0
:0.0.0.0
:0.0.0.0
:********
:Local
:0.0.0.0
:0.0.0.0
:********
to set up
