8. Unpack each modem card, observing standard static electricity
precautions. Engage the edges of the MT5634HD16 card(s) in the metal
card guides of a slot 3,7,11, or 15 and slide it in until you feel it mate with
the bus connectors inside the chassis. Engage the edges of the
MT5634HD8 card(s) in the metal card guides of a slot 4,8,12, or 16 and
slide it in until you feel it mate with the bus connectors inside the
chassis. Tighten the retaining screws.
9. Plug the two power cord sets into AC outlets.
10. Plug one end of an Ethernet cable into the LAN Ethernet 10Base-T
connector on the back of the chassis. Plug the other end into the Ethernet
wall jack.
11. Turn on the PS9600 power supplies. The power supply indicators should
light and the controller indicators should flash during the power-on self-
test.
12. Connect one end of the provided RJ48 cable to the PRI interface jack on
the MTPRI-HD23B card, and the other end to a PRI wall jack.
Note: Do not connect the PRI line(s) until you are ready to proceed with
the configuration procedures.
13. Turn on each RASCard. The indicator in the power switch and front
panel should light.
Installation of the CommPlete Communications Server hardware is complete. Your
next step is to configure the controller, RASCard, and PRI interface so they can
communicate with the outside world. Please turn to Chapter 2.
