System Installation and Quick Start Guide
53. To change the IP Address, type 1 and ENTER. The IP Address option
54. Type the IP Address of the RASCard, for example 192.168.4.151, and
55. To change the Subnet Mask address, type 2 and press ENTER.
56. Type the network Subnet Mask and press ENTER. The Getting RAS
57. To change the Default Gateway, type 3 and press ENTER. The Default
58. Type the IP address of the network Default Gateway and press ENTER.
59. To change the Primary DNS Server address, type 4 and press ENTER.
60. Type the IP address of the Primary DNS Server and press ENTER. The
61. To change the Backup DNS Server address, type 5 and press ENTER.
62. Type the address of the Backup DNS Server and press ENTER. The
63. To change the Ethernet Frame Type, type 6 and press ENTER. The
64. Type 1 to select Type_II or 2 to select SNAP and press ENTER. The
42
If no changes are needed, or all necessary changes have been made, type
d and ENTER. Proceed to RASCard Setup step # 73.
appears:
IP Address
Enter Selection (-(previous), q(uit), <2>):
press ENTER. The Getting RAS Info menu reappears.
Subnet Mask
Enter Selection (-(previous), q(uit), <2>):
Info menu appears.
Gateway menu option appears:
Default Gateway
Enter Selection (-(previous), q(uit), <2>):
The Getting RAS Info menu reappears.
The Primary DNS Server option appears:
Primary DNS Server
Enter Selection (-(previous), q(uit), <2>):
Getting RAS Info menu reappears.
The Backup DNS Server option appears.
Backup DNS Server
Enter Selection (-(previous), q(uit), <2>):
Getting RAS Info menu reappears.
Frame Type option appears.
Frame Type
1. TYPE_II
2. SNAP
Enter Selection (-(previous) <1>):
Getting RAS Info menu reappears.
:192.168.4.151
:255.255.255.0
:192.168.4.150
:192.168.4.150
:0.0.0.0
