6.4 Registers
6.4 Registers
31 30 29 28 27
0x0 0 1 1 0x01
RMT_MEM_PD This bit is used power down the entire RMT RAM block (Only exists in
RMT_CH0CONF0). 1: memory is powered down 0: memory is powered up (R/W)
RMT_CARRIER_OUT_LV_CHn
transmit on low output level, 0: transmit on high output level. (R/W)
RMT_CARRIER_EN_CHn
modulation enabled 0: carrier modulation disabled (R/W)
RMT_MEM_SIZE_CHn
channel n (R/W)
RMT_IDLE_THRES_CHn
than reg_idle_thres_chn
RMT_DIV_CNT_CHn
Espressif Systems
Register 6.1: RMT_CHnCONF0_REG (n: 0-7) (0x0058+8*n)
24 23
This bit is used to configure when the carrier wave is transmitted. 1:
This is the carrier modulation enable control bit for channeln. 1: carrier
This register is used to configure the amount of memory blocks allocated to
In receive mode, when no edge is detected on the input signal for longer
channel clock cycles, the receive process is finished. (R/W)
This register is used to set the divider for the channel clock of channel n. (R/W)
6 REMOTE CONTROLLER PERIPHERAL
0x01000
85 ESP32 Technical Reference Manual V1.0
8 7
0x002
0
Reset
