ESP32
Audio Design Guidelines
www.espressif.com
Version 1.0
Espressif Systems
Copyright © 2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ESP32 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Espressif Systems ESP32

Summary of Contents for Espressif Systems ESP32

  • Page 1 ESP32 Audio Design Guidelines Version 1.0 Espressif Systems Copyright © 2019 www.espressif.com...
  • Page 2 About This Guide The guidelines outline recommended design practices when developing Audio products based on the ESP32. Release Notes Date Version Release notes 2019.01 V1.0 Initial release. Documentation Change Notification Espressif provides email notifications to keep customers updated on changes to technical documentation.

  • Page 3: Table Of Contents

    2.1.1. PCB Layers ........................2.1.2. General Guidelines for Routing Traces ................. 2.2. Key Points of PCB Layout Design ..................... 2.2.1. Positioning an ESP32 Module on a Baseboard ............2.2.2. Positioning Plug-in Components ................2.2.3. Positioning Chip Components ................... 2.3. Power Traces, Ground Traces, and Signal Traces ..............

  • Page 4: Schematic Design

    • Power supply and GND plane. • Design rules of audio chips. • Pin configuration of the ESP32 module. 1.1. Power Supply and GND Plane 1.1.1. USB/Battery Power Scheme When the module works in Wi-Fi mode, peak current in the circuit is very high. The suggested output current for the module's power supply is no less than 500 mA.

  • Page 5: Power Scheme For Peripherals

    The power management chip of your choice should meet the circuit requirements for input and output of current and voltage, low noise, efficiency and other aspects of the circuit. For example: Power Supply for ESP32: VDD33 AP7361C-33-ER-7/13 0R(5%) 3.3V/800mA...

  • Page 6: Design Rules For Audio Chip

    1. Schematic Design Figure 1-3. Circuit for Splitting Ground Planes 1.2. Design Rules for Audio Chip Each chip has its own design rules. For example, a codec might require very strict rules for digital and analog signals, otherwise unwanted noise might occur. Digital signal processors (DSP) might require different reference ground planes.

  • Page 7: Pin Configuration Of Esp32

    Figure 1-5. Reference Circuit Design for a Codec Ground Plane 1.3. Pin Configuration of ESP32 Most pins of an ESP32 module can be reconfigured with high flexibility, according to your requirements, but there are still some guidelines that you need to follow.

  • Page 8: Dedicated Pins

    ESP32 cannot identify USB directly, so a USB to UART chip is needed in your design, such as CP2102- GM. The UART pin of the chip is connected with the UART0 pin of ESP32, which can be used to flash programs to ESP32 and serves as an interactive interface with the PC.

  • Page 9: Strapping Pins And Other Special Pins

    1. Schematic Design Figure 1-7. Reference Circuit for USB-UART Chip 1.3.5. Strapping Pins and Other Special Pins GPIO0 is one of the strapping pins, and its level state in the power-on reset process is • related to download: - “1”: enter Flash startup mode, and the chip defaults to “1”. - “0”: enter download mode.
  • Page 10 GPIO12 cannot conflict with the output voltage of LDO. • Pins used as ADC, DAC, TouchPad, SD card, JTAG, RTC domain pins required in low- power sleep mode, etc. are all special pins. Please refer to ESP32 Datasheet while configuring these pins.
 Espressif ! /19 2019.01...

  • Page 11: Pcb Layout Design

    Components can be placed either on the TOP layer or BOTTOM layer according to the actual situation, but it is recommended to set the adjacent layer of ESP32 module as GND layer. Even if ESP32 module is placed on the BOTTOM layer, it is recommended to set the third layer as a GND layer and the second layer as a POWER layer.

  • Page 12: Key Points Of Pcb Layout Design

    Figure 2-2. Non-recommended Trace Routing 2.2. Key Points of PCB Layout Design 2.2.1. Positioning an ESP32 Module on a Baseboard Place the module's PCB antenna area outside the baseboard, but put the module as close to the edge of the baseboard as possible, so that the antenna's feed point is closest to the board edge.
  • Page 13 2. PCB Layout Design Figure 2-3. ESP32 Module Antenna Position on Baseboard �� Note: As shown in Figure 2-3, the recommended position for an ESP32 module on the baseboard is: Position 3: Highly recommended. Position 4: Recommended. Position 1, 2, 5: Not recommended.

  • Page 14: Positioning Plug-In Components

    2. PCB Layout Design Figure 2-5. Reference Design for Module Placement 2.2.2. Positioning Plug-in Components For the USB interface, battery socket holder, power switch, SD card, headphone socket, external speaker socket, debugging pin header, mounting hole, etc., the positioning of their components should adhere to the following principles: Taking component structures into account, trying to make mounting/connecting easy.
  • Page 15 2. PCB Layout Design Figure 2-6. Positioning Plug-in Components Figure 2-7. Positioning Plug-in Components Espressif 2019.01...

  • Page 16: Positioning Chip Components

    2. PCB Layout Design 2.2.3. Positioning Chip Components It is recommended to place the chip components and their peripherals together, especially the filter capacitor for the power supply. These capacitors must be placed as close to the power pins as possible and distributed evenly. Please make sure you have a filter capacitor near each power pin, but do not stack all the capacitors in one place.

  • Page 17: Power Traces, Ground Traces, And Signal Traces

    2. PCB Layout Design Figure 2-9. Reference Placement for Chip Components 2.3. Power Traces, Ground Traces, and Signal Traces 2.3.1. Power Traces Routing The width of power traces and vias (holes) through layers should meet the requirements of current flowing: •...

  • Page 18: Ground Traces Routing

    2. PCB Layout Design It is recommended to separate different power traces from each other by ground • traces and to plate copper for power supplies on adjacent layers to avoid overlapping. It helps to reduce mutual interference. In the figure below, red and purple represent power copper for different purposes, and blue represents ground copper.
  • Page 19 2. PCB Layout Design Figure 2-11. Reference Design for Ground Trace Routing Figure 2-11. Reference Design for Ground Trace Routing Espressif 2019.01...

  • Page 20: Signal Traces Routing

    2. PCB Layout Design Figure 2-11. Reference Design for Ground Trace Routing 2.3.3. Signal Traces Routing • For the I2C, I2S, and UART groups, each respective group's traces should run parallel with as wide spacing as possible and be isolated from other groups with GND copper foil.
  • Page 21 2. PCB Layout Design Figure 2-15. Reference Design for Audio Signal Trace Routing Figure 2-16. Reference Design for TouchPad Traces Routing Espressif 2019.01...
  • Page 22 Disclaimer and Copyright Notice Information in this document, including URL references, is subject to change without notice. THIS DOCUMENT IS PROVIDED AS IS WITH NO WARRANTIES WHATSOEVER, INCLUDING ANY WARRANTY OF MERCHANTABILITY, NON-INFRINGEMENT, FITNESS FOR ANY PARTICULAR PURPOSE, OR ANY WARRANTY OTHERWISE ARISING OUT OF ANY PROPOSAL, SPECIFICATION OR SAMPLE.
