4.13 Registers
31 27 53
0 0 0
RTCIO_EXT_WAKEUP0_SEL GPIO[0-17] can be used to wake up the chip when the chip is in sleep
mode. This register selects the pad source to wake up the chip in deep/light sleep mode. 0: select
GPIO0; 1: select GPIO2, etc. (R/W)
31 27 53
0 0 0
RTCIO_XTL_EXT_CTR_SEL Select the external crystal power down enable source in sleep
mode. 0: select GPIO0; 1: select GPIO2, etc.
CIO_RTC_EXT_XTAL_CONF_REG[30] is the crystal power down enable signal. (R/W)
31 30 29 28 55
0 0 0 0 0
RTCIO_SAR_I2C_SDA_SEL Selects a different pad as the RTC I2C SDA signal.
TOUCH_PAD[1]; 1: use pad TOUCH_PAD[3]. (R/W)
RTCIO_SAR_I2C_SCL_SEL Selects a different pad as the RTC I2C SCL signal.
TOUCH_PAD[1]; 1: use pad TOUCH_PAD[3]. (R/W)
Espressif Systems
Register 4.54: RTCIO_EXT_WAKEUP0_REG (0x002f)
