CAUTION–POSSIBLE EQUIPMENT
DAMAGE: Do not place light
guide/ultrasound connectors
on their cables or damage
may result.
Hold Insertion Tube Near Control Handle Boot
IMPORTANT:
Opening to Prevent Excessive Bending or Kinking.
Insertion Tube
Control
Handle
Light Guide Cable
Figure 4-6. Insert Insertion Tube Into Control
Handle Boot Opening
Processing Instructions
b. Carefully feed distal end of insertion tube into insertion tube
slide
into slide.
IMPORTANT: Hold insertion tube near control handle boot
opening to ease insertion and prevent damage caused by
kinking or excessive bending.
NOTE: For insertion tubes that are hard to insert into tube
slide, wet tube with water to ease insertion.
12. If using split insertion tube sleeve (NOT labeled with a color
dot),
a. Open split insertion tube sleeve as shown in Figure 4-8.
Control Handle
Boot Opening
WITHOUT a Color
Identification

Figure 4-8. Split Insertion Tube Sleeve

Operator Manual
(see Figures 4-6 and
proceed as follows (see
Endoscope Control
Handle
Universal
Cord Port
Figure 4-7. Place Control Handle in Control
Opening Split Insertion Tube Sleeve
4-7). Feed entire insertion tube
Figure 4-8):
Handle Boot
Insertion
Tube
Slide
Strain
Relief
Boot
Flaps
Light
Guide
Cable
4-9
