Steris AMSCO 2532 Operator's Manual

Single-chamber washer/disinfector
Hide thumbs
Table of Contents

Advertisement

Quick Links

10041925
Revision M
AMSCO® 2532
Single-Chamber Washer/Disinfector
Operator Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AMSCO 2532 and is the answer not in the manual?

Questions and answers

Mario Magana
May 20, 2025

How do I reset the alarm to run another cycle
