6.12 Rotary Spray Arm
WARNING – ELECTRIC SHOCK
AND/OR BURN HAZARD:
• Disconnect all utilities to
processor before servicing.
Do not service processor
unless all utilities have
been properly locked out.
Always follow
electrical codes and safety-
related work practices.
• Pressing bottom portion of
POWER (ON/OFF) toggle
switch to turn off processor
DOES NOT cut off electrical
power. Lockout/Tagout
building electrical disconnect
switch to turn off power to
processor for maintenance
or repairs.
• Fasteners and star washers
are used to ensure protective
bonding continuity. Always
reinstall any star washer
which may
removed during installation
or servicing.
WARNING – SLIPPING HAZARD:
To avoid slippery
conditions, immediately wipe
up any spilled liquids
drippage. If spilled liquids or
drippage are detergents or
other chemicals, follow safety
precautions and
procedures set
detergent or chemical label
and/or Safety
(SDS).
Routine Maintenance
See Figure 6-8.
Assembly
1. Clean processor chamber rotary spray arm assembly as follows:
a. At top of chamber, loosen thumb screw from rotary spray
b. Remove and lower rotary spray arm assembly.
c. Clean spray arms under running water.
d. Use a fine wire (approximately wire gauge of a paper clip) to
e. Install rotary spray arm assembly into ceiling of chamber.
2. To clean rotary spray arm assembly of endoscope processing
local
support, repeat Steps b to d then reinstall.
have been
floor
or
handling
forth on
Data Sheet
Operator Manual
arm assembly.
clean out sediment from spray nozzles. Rinse under running
water.
Tighten thumb screw.
Thumb Screw

Figure 6-8. Rotary Spray Arm Assembly

Rotary Spray Arm
6-19
