NB3710 User Manual 4.0
4.7. Installation of the Local Area Network
Up to five 10/100 Mbps Ethernet devices can be directly connected to the router, fur-
ther devices can be attached via an addtional Ethernet switch. Please ensure that the
connector has been plugged in properly and remains in a fixed state, you might other-
wise experience sporadical link loss during operation. The Link/Act LED will lit up as
soon as the device has synced. If not, it might be necessary to configure a different link
setting as described in chapter 5.3.2.
4.8. Installation of the Power Supply
The router can be powered with an external source supplying between 12 V
and 48 V
.
DC
DC
It is to be used with a certified (CE or equivalent) power supply, which must have a
limited and SELV circuit output. The router is now ready for getting engaged.
