3. Click Import ( ).
2
NOTE: It may take up to 30 seconds to import settings. A dialog box opens to indicate
a successful import.
To export a system configuration, click Export (
automatically stored in the default download directory of the web browser.
Using a Configuration File to Update VoIP Settings
The Import System Configuration panel can be used to update advanced VoIP
settings. This may be required when configuring the DMP Plus to be compatible with certain
VoIP systems.
NOTE: For more detailed instructions and information on various types of VoIP systems,
see the article at www.extron.com/article/voip.
To configure the advanced VoIP settings:
NOTES:
Importing a .conf file will apply updates only to the respective settings that are
•
included in the file. Default or other current settings on the device are not reset or
removed by importing a new .conf file.
• Multiple settings can be changed when importing a single .conf file. It is not
necessary to make a separate .conf file for each desired setting change.
1. Create a new blank text file using a suitable basic text editor, or export the current
system configuration file (see "To export a system configuration..." in System Tab).
2. Make configuration changes by adding new text, editing the existing text, or removing
text from the file.
(Example 1) To enable the Automatic Line Re-Registration:
a. Enter the following text into the document, if not already present:
{"network":{"registration_fail_retry_count":5,"registration_fail_
retry_delay":300}}
NOTE: When enabled, this function will attempt re-registration once the SIP
timer has expired. By default the SIP timer is set to 3600 seconds (60 mins).
By default, the Automatic Line Re-Registration feature is disabled, with the
"registration_fail_retry_count" set to zero (0).
registration_fail_retry_count":5
•
This is the number of attempts a Line will make to re-register.
NOTES:
• The example above is set to five (5) reconnections attempts.
If this is set to zero (0), the feature is disabled.
•
Valid Range of values: 0 - 99
•
registration_fail_retry_delay":300
•
This is the amount of time between registration attempts in seconds.
NOTES:
The example above is set to 300 seconds (5 mins) between
•
reconnections attempts.
Valid Range of values: 120 - 3600
•
). The exported JSON file is
3
DMP 64 Plus • Internal Web Pages 88
