Advanced Options
The Advanced panel (see figure 61,
specified for redundancy purposes.
Audio
Codecs can be added or removed from the selected line in the Audio tab (see figure 62).
Codecs added to the line are available during call negotiation. A minimum of one codec
must be present in the Assigned column. Codecs placed higher on the list are treated as
preferred codecs during call negotiation.
Figure 62. VoIP Line Audio Configuration Tab
To move a codec between the Available and Assigned column, select the desired
codec and click the arrows between the columns.
To change codec priority in the Assigned column, click and drag the desired codec to
the desired position in the list.
Click Apply to save and apply the codec configurations.
Dialing
The Dialing tab allows dialing behavior to be configured for the selected line (see
figure 63).
Figure 63. VoIP Line Dialing Tab
DTMF Delivery Mode drop-down list — Select the DTMF delivery mode.
1
NOTE: Always consult with the VoIP system administrator to determine the correct
DTMF mode.
Auto-answer drop-down list — Select On or Off for auto-answer answer features.
2
Delay (seconds) — If auto-answer is enabled, enter the amount of delay in seconds
3
before the call is automatically answered.
Apply button — Click to save and apply the changes
4
on page 85) allows a secondary proxy to be
¢
DMP 64 Plus • Internal Web Pages 86
