Mode Activation
1 Hold in the recessed rear panel
Reset button while applying
power to the unit.
NOTE: Do not operate with the default firmware loaded by a mode 1 reset. Use it only to load the
most current firmware to the device.
*4 Hold in the Reset button until
reset LEDs blink twice (once at
3 seconds, again at 6 seconds).
Then, release and press the
Reset button again within
1 second*.
*5 Hold in the Reset button until
reset LEDs blink three times
(once at 3 seconds, again at
6 seconds, again at 9 seconds).
Then, release and press the
Reset button again within
1 second*.
NOTE: *For modes 4 and 5, nothing happens if the momentary press does not occur within 1 second.
Reset Modes
Result
The device reverts to the factory default
firmware for a single power cycle.
Sets the following back to factory default:
•
Digital I/O port mapping.
•
IP address for LAN 1
(192.168.254.254).
•
IP address for LAN 2
(192.168.1.254)
•
Subnet mask address for LAN 1
and LAN 2 (V-models only) =
255.255.255.0
( ).
•
Gateway IP address for LAN 1 and
0.0.0.0
LAN 2 (V-models only) = (
Enable ARP capability.
Turns off DHCP for LAN 1 and LAN 2
(V-models only)
Performs a complete reset to factory
defaults (except the firmware).
•
Includes Mode 4 factory default.
•
Mix-points are set to unity gain (0 dB)
and the following connections are
made:
•
Input 1 is routed to output 1.
•
Input 2 is routed to output 2.
•
Input 3 is routed to output 3.
•
Input 4 is routed to output 4.
•
All audio inputs are set to unity gain.
•
All outputs are unmuted and set to
unity again.
•
Any inserted or active DSP removed.
•
All preset and group master memory
is cleared.
Purpose and Notes
Use mode 1 to revert to
the factory default firmware
for a single power cycle if
incompatibility issues arise with
user-loaded firmware. All user files
and settings are maintained.
Use mode 4 to reset all IP settings
back to factory defaults.
).
Use mode 5 to start over
with default configuration and
uploading, and also to replace
events.
