In addition to EXP expansion capabilities, DMP 64 Plus AT models allow connection to a
Dante audio network for transporting audio across a TCP/IP network. This further increases
the DMP 64 Plus input and output expansion capabilities. DMP 64 Plus V models can
register up to 8 VoIP lines per device. The DMP 64 Plus V can function as a VoIP interface,
removing the need for dedicated VoIP hardware. The DMP 64 Plus has no front panel
controls. All configuration is performed using the Extron DSP Configurator software from a
host computer via Ethernet (recommended) or USB. The rear panel RS-232 port allows for
serial control via SIS commands. Signal presence and clip LEDs for the six input channels
and four output channels are on the front panel. Status indicators for EXP, LAN, and USB
audio are also on the front panel.

Features

•
•
•
•
•
•
•
•
•
•
•
•
Four models with 6 mic/line inputs and 4 line outputs
Six channels of AEC — acoustic echo cancellation
All models include a configurable USB Audio interface — Easy connectivity
to computer based soft codecs and program playback sources. The input/output
configuration of the USB Audio Interface can be set to 0x8, 2x6, 4x4, 6x2, or 8x0. This
allows for more input or output streams, as required by the system application.
AT models provide Dante audio networkworking with Dante Domain Manager
and AES67 support —
• Receives 32 channels from a Dante network
• Transmits 16 channels to a Dante network
V-models include up to eight VoIP lines that support generic Session Initiation
Protocol - SIP 2.0 connectivity per RFC 3261 — The DMP 64 Plus V models are
compatible with select VoIP systems and can be used for a single VoIP line or as a VoIP
farm for up to eight rooms.
Compact half rack size
FlexInput capability on main inputs (AT models only) — All six main inputs offer
FlexInput capability to select a Dante channel, expansion input, or a local mic/line input.
This allows incorporating the full range of DSP capabilities, including AEC, for incoming
Dante channels.
Optional ACP Series audio control panels provide intuitive audio system
control — Directly connects to the DMP 64 Plus, offering flexible audio control for
configurations that do not require a full control system.
Digital I/O ports for remote control or feedback — Six digital input and output
ports are provided, so that the DMP 64 Plus can be programmed to sense and then
respond to external triggers such as mic activation, muting, and recall of presets.
Macros allow the sequencing of commands that can be sent to the local device
or external devices via the LAN port — A single DMP 64 Plus can act as the central
interface from a control system, sending commands to other DMP and DTP CrossPoint
units.
Advanced audio processing on all four analog outputs and all 16 direct
Dante/Expansion outputs — Up to 20 speaker zones can be implemented on one
DMP 64 Plus with full processing for each zone, making it ideal for full mix-minus
implementations.
16 virtual processing loops allow for great flexibility in sub-mixing and
processing — Processing common to many inputs can be applied using a single
virtual channel.
