2. For the LAN 1 and LAN 2 panels (see figure 55,
Static for the IP Address field.
• If DHCP is selected, all other fields are greyed out.
• If Static is selected, fill out the IP Address, Subnet Mask, and Gateway fields.
For the VLAN panel (see
3.
NOTE: VLAN panel is only available when VLAN is selected from the VoIP Interface
drop-down list (see figure 55,
Figure 56. VLAN Panel
Select the DHCP or Static radio button for the IP Address field.
a.
If DHCP is selected, all other fields are greyed out.
•
• If Static is selected, fill out the IP Address, Subnet Mask, and Gateway
fields.
b. Select the LAN 1 VLAN or LAN 2 VLAN radio button.
c. Enter an appropriate VLAN ID tag in the VLAN ID field.
5. Click Apply (see figure 55,
QoS/LLDP-MED
The QoS/LLDP-MED tab allows users to set the PCP (Priority Code Point) and Differentiated
Services Code Point (DSCP) as well as enable or disable the Link Layer Discovery Protocol -
Media Endpoint Discovery (LLDP-MED) (see figure 57).
Figure 57. VoIP Network QoS/LLDP-MED Tab
2
and figure 56):
3
).
1
) to save and apply the changes.
4
DMP 64 Plus • Internal Web Pages
on page 79), select DHCP or
