To send an SIS command to an AXI device connected to a DMP 64 Plus:
1. Connect the DMP and Dante-controlled devices to the same network via their AT ports
Physical Dante Network Setup
(see
2. Connect to the DMP via the DataViewer or HyperTerminal utility (see
and Control on page 34).
3. Use the Set verbose mode command to set the DMP to Verbose mode 3 (see
verbose mode on page 46). Example:
Command
w3cv |
4. Use the Query available remote devices command (see
devices on page 52) to receive a list of Dante devices that are currently connected to
the DMP. Example:
Command
waexpr|
NOTE: This list is similar to the list displayed within Dante Controller.
6. Use the Enable remote connection for listening command to display the remote Dante-
controlled device responses based on the list of devices provided in the response
in step 4 (see Enable remote connection for listening
necessary for all desired devices. Example:
Command
wcAXI02-XTP-RoomA*1expr
NOTE: AXI devices can be set up for listening even if not currently connected to the
DMP unit.
8.
To verify that the DMP is listening to the correct remote devices, use the Query remote
devices being listened to command to display a list of all remote devices enabled with
the command in step 5 (see
Example:
Command
wlexpr|
9. Send the desired command to the AXI and confirm the correct response is received.
• When entering a command, use the "w" character in place of the <Esc> key and the
"pipe" character ( | ) in place of a return. Failing to do so may cause the command
to fail.
The closing bracket ( } ) is necessary to successfully end a command before
•
attempting to send a new command. Example:
Command
{dante@AXI02-XTP-
RoomA:wg40000*-10AU|}|
NOTE: The DMP provides the tag showing the Dante-controlled remote device
name while the remote device provides the response for the SIS command.
on page 27).
Response
]
Vrb3
Response
•
ExprA AXI-XTP-RoomA
]]
AXI-XTP-RoomB
Response
| ExprCAXI-XTP-RoomA*1
Query remote devices being listened to
Response
•
ExprL AXI-XTP-RoomA
Response
{dante@AXI02-XTP-RoomA}DsG40000*-10
DMP 64 Plus • Dante Controller
SIS Configuration
Set
Query available remote
]
on page 52). Repeat if
]
on page 52).
]
]
