Disconnecting Inputs from Outputs

To undo routing, click the junction again to disconnect the receiver from the transmitter.
NOTE: After making changes to Dante network routing such as subscriptions, device

AES67 Mode

The AT models of the DMP Plus series support the AES67 audio over IP interoperability
standard. This feature allows audio transport to and from other AES67-compatible devices,
such as the Extron NAV series.
To enable AES67 mode:
1.
2.
3.
4.
To create an AES67 Multicast Flow:
1.
2.
3.
4.
5.
6.

Dante Troubleshooting

The most common Dante troubleshooting issues occur when devices are not discovered by
Dante Controller or when routing is not successful. Both issues occur when software is not
able to properly discover devices operating on the Dante network.
Before moving into more difficult troubleshooting, shut down Dante Controller and reseat the
Ethernet cable connecting the PC to the Dante network and restart Dante Controller. This
can be enough for the software to reacquire the Dante network.
If the problem persists, perform the following troubleshooting procedures in the order listed.
names, or channel labels, wait at least 5 seconds before disconnecting or powering
down the devices. This ensures that the new information is properly saved to those
devices. Device level configuration such as sample rates, latency, and clock settings
are saved instantly.
Open Dante Controller and double-click
the Dante device name in the Routing
tab to open Device View.
Click on the AES67 Config tab.
The configuration screen opens (see
figure 36).
Select Enabled from the drop-down list
( ).
1
Click the Reboot button (
2
the device and enable AES67.
Open Dante Controller and double-click the Dante device name in the Routing tab to
open Device View.
Click the Create a new multicast flow button.
In the Flow Config section, click the AES67 radio button.
In the Flow Config section, select Auto or Manual Destination Address. If manual
is selected, enter the destination address.
Check the box for each channel to be included in the Multicast Flow.
Click Create.
) to reboot
Figure 36.
DMP 64 Plus • Dante Controller
AES67 Mode
