Connecting to DSP Configurator

1.
2.

Accessing the DSP Configurator Help File

DSP Configurator comes loaded with a context-sensitive help file that can be accessed by
clicking the help icon (
Alternatively, click Help > Contents in the menu bar at the top of the main workspace,
or press <F1> on your keyboard. This help file contains detailed procedures and further
instruction on all DSP Configurator features.

DSP Configurator Main Workspace

NOTE: For details about specific software features and device configurations, refer to
The DSP Configurator main workspace contains various functions to configure the
DMP 64 Plus (see figure 16). Use the expand and collapse buttons (
and output group names to show or hide input and output groups and their corresponding
mix matrices. If necessary, scroll through the window by using the mouse wheel or the scroll
bar at the right side of the DSP Configurator main workspace.
Figure 16.
Open the DSP Configurator Software program from the desktop shortcut.
Alternatively, to run DSP Configurator
from the default install location, click
Start> Programs> Extron>
DSP Configurator.exe
The Extron DSP Configurator
splash screen opens (see figure 15).
From the DSP Configurator splash
screen drop-down list ( ), select the
1
DMP 64 Plus being connected to the
host PC and click OK ( ).
2
) in the top right corner of any dialog box in DSP Configurator.
the DSP Configurator Help File.
DMP 64 Plus DSP Configurator Main Workspace
Figure 15. DSP Configurator
DMP 64 Plus • DSP Configurator Software
) next to the input
15
