Mode Data

This area will contain information that relates to the currently selected Display Mode.

Settings Button

The Settings Button will open a Settings area, which
contains menus for Display Mode Settings,
General Settings, Serial Port Settings, Diagnostic
Settings and Date & Time Settings.
The Display Mode settings shown on the Settings
screen depend on which mode has been selected. You
can find information about the settings for each mode in
the specific mode areas.
Screenshot Button
By pressing the Screenshot Button you can save a full
image of what is currently shown on the screen. This
screenshot will be saved to the inserted SD card as a
1.5 MB bitmap image, orientated at 90° to the original
screen image and with the prefix 'screenshot'.The LEDs
will illuminate yellow in sequence from left to right to
display the progress of writing to the SD card. When the
screen capture is complete, VBOX Touch will emit an
audible confirmation notification. If the screenshot could
not be saved, for example, no SD card is inserted or the
card is full, the SD Card Icon at the top of the screen
will flash 3 times and VBOX Touch will emit an audible
error notification.
IMPORTANT
NEVER remove the SD card while a screenshot is
captured and saved as it could cause the unit to
crash!
