• Lap is over half the stored reference lap distance.
• Lap time does not exceed 43'40.00".
It is also possible to choose to ignore short laps from creating the reference lap by entering a Minimum Lap Time within
the Settings.
When a reference lap is being created, a 'Creating a Reference Lap' message is displayed on the Main Lap Timing
Screen within the Delta-T section and the reference lap section will show a rolling lap time. The LEDs will also illuminate
blue
during the creation process.
The reference lap will update if a faster lap is achieved or if the lap distance is more than double the stored reference
lap, unless the Reference Lap has been Fixed within the Settings.
Reference laps can also be Loaded from previously saved or provided files, or Saved for future use.
The reference lap will be retained after each power cycle.
Lap Timing Settings
The Lap Timing settings screen can be accessed by selecting the Settings Button
on the bottom left of the screen and then selecting the Lap Timing option. It is split in to 2 pages and enables you to
choose the lap timing parameters.
The different pages can be accessed by selecting the Forward
and Back
arrows on the bottom right of the screen or by swiping the screen left or right.
User_Guide_%E2%80%93_VBOX_Touch_V2/05_Display_Modes_%E2%80%93_VBOX_Touch_V2/VBOX_Touch_V2_-
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_V2/
_Lap_Timing_Mode
58
