to VBOX Test Suite via an RLCAB001 and conduct live
testing, or output lap timing parameters. You can find
more information about the Serial Output settings here.
You can find more detailed connector information on the
PIN OUTS page.
Mounting
VBOX Touch is supplied with a Swivel Neck Richter Suction Mount (RLACS277) for mounting onto a vehicle
windscreen. It can also be secured using the ¼ 20 TPI UNC screw thread on the back of the unit.

Satellite Reception

VBOX Touch has an internal patch antenna. This means that in most circumstances where the unit has a clear view of
the sky and no interference, you do not need an additional external antenna. However, if you are struggling to maintain a
stable satellite lock (indicated by a flashing red satellite icon), you can use the external antenna (RLACS262) supplied
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_V2/
User_Guide_%E2%80%93_VBOX_Touch_V2/02_Installing_VBOX_Touch_V2_in_Your_Vehicle
Right Side
