VBOX Touch - RS232 Output
The RS232 output is present on the
computer for testing online with
VBOX Data Format
This is output when VBOX Stream
Protocol:
115200 Baud, no parity, 8 data bits, 1 stop bit
Message format:
$VBTse$StttaaaaaaoooooovvvhhAAAVVVxxyysddTTcc
Parameter
$VBTse$
S
ttt
User_Guide_%E2%80%93_VBOX_Touch_V2/07_Technical_Properties_%E2%80%93_VBOX_Touch_V2/VBOX_Touch_-
top CAN/Serial port
VBOX Test Suite or for outputting laptiming data.
is selected within the Serial Port Settings menu.
Number of bytes
7
1
3
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_V2/
of VBOX Touch and can be used to provide a connection to a
Description
Header
Message identifier as ASCII string.
Total satellites
Number of satellites used in solution
irrespective of GNSS. Range (0,
255).
Note: All eight bits are used.
Time
Ticks since midnight UTC. Range
_RS232_Output
