VBOX Touch V2 - Decel Mode
The Deceleration Mode allows you to perform deceleration tests using pre-defined configurations, using your own
specified values or by using a VBOX Brake Pedal Trigger. It is accessed by pressing the Mode Button
at the bottom of the screen and selecting Decel.
The last selected Deceleration test will be displayed after each power cycle. Speed parameters are used to start and
end the test. Test results displayed on the screen of the VBOX Touch will remain on screen at the end of the test until
the next start condition is met.
