When there is no satellite lock, the icon will flash red.

Display Mode

This header shows which

Battery Status

The Battery status icon is there to keep you informed of the charge currently available in the battery when you are
using the battery with the Performance Box Touch. You can read more about the battery status here.

Mode Data

This area will contain information in relation to the currently selected

Settings Button

The Settings Button will open a Settings area which
contains Display Mode,
Settings.
The options presented first within the Settings screen
are dependent on the mode selected, information on
these can be found within each specific mode area.

Screenshot Button

Selecting the Screenshot Button will save a full image
of what is shown on screen to the inserted SD card. If
the screenshot has been saved successfully, the LEDs
will illuminate yellow in sequence from left to right to
display the progress of writing to the SD card. When
screen capture is complete, Performance Box Touch
will emit an audible confirmation notification. If the
screenshot has been saved unsuccessfully, for example,
no SD card is inserted or the card is full, the SD
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/Performance_Box_Touch/Performance_Box_Touch_V1/
User_Guide_%E2%80%93_Performance_Box_Touch_V1/03_Screen_Layout_%E2%80%93_Performance_Box_Touch_V1
Display Mode is currently selected.
General and Diagnostic
Display Mode.
