The first time that the unit is booted up, the Display Mode screen will be presented. Every time after this, the last used
display mode will be opened.
Logging
VBOX Touch logs data via an SD card inserted into the side of the unit. Depending on the Logging Strategy selected
within the General Settings area, the unit will either log continuously or when movement is detected (default).
Tapping on the SD Card Icon when green will manually start or stop logging data, overriding the Configured Logging
Strategy.
The Record Icon will show when the unit is logging data to the SD card.
If you have come to a stop, but the Record Icon is still on, press the SD Card Icon to stop the logging before removing
the card.
Sometimes, due to poor satellite visibility in a garage or close to a building, VBOX Touch may start recording, even if the
car is stationary. Always check the Record Icon before ejecting the card.
IMPORTANT
Do not remove the SD card when the Record Icon is on as you may lose data.
Note: If for some reason the SD card is removed while the unit is still recording, it may need to be repaired using a PC
before it can be reused.
Logging Switch
You can also control the logging by using an RLVBACS010 hand-held latching trigger switch (unlatched for logging/
latched for not logging). Continuous Logging Mode should be selected when using the switch. It is connected to the
3-pin Digital In and PPS Connector on the side of the VBOX Touch.
When the trigger switch is connected and latched, it is not possible to use the SD Card Icon to manually start or stop
logging data.
Logged Channels
VBOX Touch logs channels to an inserted SD card within a .vbo file, channel information is available below:
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_V2/
User_Guide_%E2%80%93_VBOX_Touch_V2/01_Getting_Started_%E2%80%93_VBOX_Touch_V2
