VBOX Touch - PIN OUTS
Connector 1 - GNSS Antenna
PIN
Centre
Chassis
User_Guide_%E2%80%93_VBOX_Touch_V2/07_Technical_Properties_%E2%80%93_VBOX_Touch_V2/VBOX_Touch_-
Right side view of VBOX Touch
I/O
I
I
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_V2/
Function
RF Signal/Power for active antenna
Ground
_PIN_OUTS
79
