Battery Status; Mode Data; Settings Button; Screenshot Button - Racelogic Performance Box Touch V2 Manual

Battery Status

If you are using the separate battery to power Performance Box Touch, the Battery status icon is there to keep you
informed of the charge currently available in the battery. You can read more about the battery status here.

Mode Data

This area will contain information that relates to the currently selected

Settings Button

The Settings Button will open a Settings area, which
contains menus for Display Mode settings,
General settings, Diagnostic
settings.
The Display Mode settings shown on the Settings
screen depend on which mode has been selected. You
can find information about the settings for each mode in
the specific mode areas.

Screenshot Button

By pressing the Screenshot Button you can save a full
image of what is currently shown on the screen. This
screenshot will be saved to the inserted SD card as a
1.5 MB bitmap image, orientated at 90° to the original
screen image and with the prefix 'screenshot'.
The LEDs will illuminate yellow in sequence from left to
right to display the progress of writing to the SD
card. When the screen capture is
complete, Performance Box Touch will emit an audible
confirmation notification. If the screenshot could not be
saved, for example, no SD card is inserted or the card is
full, the SD Card Icon at the top of the screen will flash
3 times and Performance Box Touch will emit an audible
error notification.
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/Performance_Box_Touch/Performance_Box_Touch_V2/
User_Guide_%E2%80%93_Performance_Box_Touch_V2/03_Screen_Layout_%E2%80%93_Performance_Box_Touch_V2
Settings and Time
Display Mode.
