IMPORTANT
Do not remove the SD card when the Record Icon is red. You may lose data or damage the SD card if you
remove it while the unit is logging.

SD Status

The SD Card Icon displays the status of the recording
media. When an SD card has been inserted and has
free space, the icon will be green. By tapping on the
icon when it is green, you can manually start or stop the
data logging and override the Configured Logging
Strategy.
If the unit cannot detect an SD card or the media is full
or corrupted, the icon will be red.

Satellite Status

The Satellite Icon illustrates whether the unit has a valid
satellite lock.
When a lock is acquired, this icon will be
If there is no satellite lock, the icon will

Display Mode

The header shows which Display Mode is currently selected.

Mode Data

This area will contain information that relates to the currently selected Display Mode.
VBOX_Touch_(v1)/User_Guide_%E2%80%93_VBOX_Touch_(v1)/04_Screen_Layout_%E2%80%93_VBOX_Touch_(v1)
solid green.
flash red.
