Screenshot
Selecting the Screenshot Button
will save a full image of what is shown on screen to the inserted SD card. If the screenshot has been saved
successfully, the LEDs will illuminate
card. When screen capture is complete, VBOX Touch will emit an audible confirmation notification. If the screenshot has
been saved unsuccessfully, for example no SD card is inserted or the card is full, the SD Card Icon at the top of the
screen will flash 3 times and VBOX Touch will emit an audible error notification.
A captured image is saved as a 1.5 MB bitmap image, orientated at 90° to the original screen image, with the
prefix 'screenshot'.
IMPORTANT
– NEVER remove the SD card when a screenshot is being taken, it could cause the unit to crash!
Test History
A history of the test results can be viewed by selecting the Results Button
at the bottom of the Primary Accel Screen.
Test results will display until a new test type is chosen or the Reset Button is pressed.
User_Guide_%E2%80%93_VBOX_Touch_V2/05_Display_Modes_%E2%80%93_VBOX_Touch_V2/VBOX_Touch_V2_-
yellow
in sequence from left to right to display the progress of writing to the SD
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_V2/
_Accel_Mode
33
