Racelogic VBOX Touch V2 User Manual page 46

Minimum/ Maximum Values
From
• Speed
◦ The maximum From speed selectable is the value inputted as Minimum Trigger Speed.
◦ The minimum From speed selectable is the greater value of 5 km/h or the To value +1.
Note: The maximum input value for speed is 999.9 and can be entered up to 1 decimal place.
• Percentage
◦ The maximum From percentage selectable is 100%.
◦ The minimum From percentage selectable is the To value +1.
To
• Speed
◦ The maximum To speed selectable is the From value -1.
◦ The minimum To speed selectable is 0.
• Percentage
◦ The maximum To percentage selectable is the From value -1.
◦ The minimum To percentage selectable is 0.
Decel Settings
The Decel Mode settings screen can be accessed by selecting the Settings Button
on the bottom left of the screen and then selecting the Decel option. It enables you to choose the test parameters and
also includes other test options.
User_Guide_%E2%80%93_VBOX_Touch_V2/05_Display_Modes_%E2%80%93_VBOX_Touch_V2/VBOX_Touch_V2_-
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_V2/
_Decel_Mode
46
