When a lock is acquired, this icon will be solid green.
If there is no satellite lock, the icon will flash red.
When VBOX Touch RTK has a GNSS status of RTK
Float, this icon will be orange.
When VBOX Touch RTK has a GNSS status of RTK
Fixed, this icon will be purple.
Display Mode
The header shows which Display Mode is currently selected.
Mode Data
This area will contain information that relates to the currently selected Display Mode.
Settings Button
The Settings Button will open a Settings area which
contains menus for Display Mode Settings,
General Settings, Serial Port Settings, Diagnostic
Settings, Date & Time Settings and CAN Bus
Settings.
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_RTK/
User_Guide_%E2%80%93_VBOX_Touch_RTK/04_Screen_Layout_%E2%80%93_VBOX_Touch_RTK
3
