VBOX Touch User Manual
•
01 - VBOX Touch Introduction
•
02 - VBOX Touch Getting Started
•
03 - VBOX Touch Screen Layout
•
04 - VBOX Touch Display Modes
•
VBOX Touch - Accel Mode
•
VBOX Touch - Decel Mode
•
VBOX Touch - Lap Timing Mode
•
VBOX Touch - Speed Display Mode
•
05 - VBOX Touch Settings
•
06 - VBOX Touch RTK
•
07 - VBOX Touch Data Analysis Software
•
08 - VBOX Touch Technical Properties
•
VBOX Touch - EC Declaration of Conformity
•
VBOX Touch - PIN OUTS
•
VBOX Touch - Technical Specification
•
VBOX Touch - Installing/Updating an App
•
VBOX Touch - Updating the Firmware
•
VBOX Touch - Updating the Track Database
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VBOX Touch and is the answer not in the manual?

Questions and answers

Related Manuals for Racelogic VBOX Touch

Summary of Contents for Racelogic VBOX Touch

  • Page 1 VBOX Touch - Speed Display Mode • 05 - VBOX Touch Settings • 06 - VBOX Touch RTK • 07 - VBOX Touch Data Analysis Software • 08 - VBOX Touch Technical Properties • VBOX Touch - EC Declaration of Conformity •...
  • Page 2 New applications can be loaded by inserting an SD card containing the new script and it is just as quick to revert to the standard functionality of the VBOX Touch by inserting the SD card containing the original data.

  • Page 3: Left Side

    Left Side SD Card VBOX Touch logs data via an SD card. Dependent on the Logging Strategy selected within the General Settings area, the unit will either log continuously or when movement is detected (default). More information on this is available here.

  • Page 4: Right Side

    Antenna VBOX Touch has an internal patch antenna, meaning that in many circumstances where the unit has a clear view of the sky without any interference, an additional antenna is not required. However, if you are struggling to maintain a stable satellite lock, the supplied external antenna (RLACS262) can be connected to the antenna socket.

  • Page 5: Standard Inventory

    Power The VBOX Touch unit is either powered by the supplied RLCAB010LE cable (RLVBTOUCH) which is inserted in to a vehicle's 12 V cigar power socket, or by the RLCAB014LE cable (RLVBTOUCH-M) which is unterminated for making a bare wire connection to a power supply. More information on this is available here.
  • Page 6 Product Code Quantity Description RLACS277 Swivel Neck Richter Suction Mount RLACS281 Plastic Carry Case for VBOX Touch https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/01_- _VBOX_Touch_Introduction...

  • Page 7: Optional Accessories

    Optional Accessories Product Code Description RLVBACS004 Brake Pedal Trigger RLVBACS010 Hand Held Start/Stop Logging Switch RLCAB001 VBOX PC Serial Cable https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/01_- _VBOX_Touch_Introduction...
  • Page 8 Register your unit here. Power The VBOX Touch unit is either powered by the supplied RLCAB010LE cable (RLVBTOUCH) which is inserted in to a vehicle's 12 V cigar power socket, or by the RLCAB014LE cable (RLVBTOUCH-M) which is unterminated for making a bare wire connection to a power supply.
  • Page 9 The first time that the unit is booted up, the Display Mode screen will be presented. Every time after this, the last used display mode will be opened. https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/02_- _VBOX_Touch_Getting_Started...

  • Page 10: Satellite Reception

    External Antenna (If Required) Placement of the GNSS antenna is crucial to the quality of the data recorded by VBOX Touch. Any metal close to a GNSS antenna can disturb the signal in an unpredictable way due to interference from reflections of weak https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/02_-...
  • Page 11 If this is not possible, copper or aluminium foil can be used to create a shaped ground plane underneath the antenna. For example, on a fibreglass roof, mount the antenna on top of the roof, and place some adhesive backed metal foil underneath, on the inside of the roof. https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/02_- _VBOX_Touch_Getting_Started...

  • Page 12: Gps Coldstart

    GPS Coldstart If VBOX Touch is struggling to acquire satellite lock, a GPS coldstart may be required. This may be necessary when the unit hasn’t been used for a number of days or has dramatically moved location since its last use.
  • Page 13 ‘SEARCHING FOR SATELLITES’ until satellite lock has been acquired. It will take approximately 25 – 30 seconds for the unit to reacquire satellite lock. Logging VBOX Touch logs data via an SD card inserted in to the Side of the Unit. Dependent on the Logging Strategy selected within the General Settings area, the unit will either log continuously or when movement is detected (default).

  • Page 14: Sd Card Format

    SD Card Format VBOX Touch is supplied with an 8 GB SDHC card in a FAT32 file format, which is the only file format supported. If you are looking to purchase a new SD card, it is recommended that any card used has a write speed of above 7 MB/s (4 MB/s absolute minimum) and a speed class of 10 (4 absolute minimum).
  • Page 15 • Event 1 time: This is the digital input oversample timer used to interpolate the trigger event time between captured samples. • Correction age (VBOX Touch RTK only): RTK signal age in seconds, if there is a loss in connection, the value resets at 60 s.
  • Page 16 03 - VBOX Touch Screen Layout As the name suggests, VBOX Touch is controlled by using the capacitive touch screen. Generally, the top of the screen contains indicative status information, the centre of the screen contains mode/settings information which can be navigated by pressing fwd/back buttons or by swiping the screen left/right, and the bottom of the screen contains function buttons.
  • Page 17 The Satellite Icon displays the current GNSS status. More information on the different GNSS states can be found here. Solid Green - Standalone Flashing Red - No positional accuracy; Code satellite lock Diff/SBAS positional accuracy Solid Orange - RTK Float Solid Purple - RTK Fixed https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/03_- _VBOX_Touch_Screen_Layout...
  • Page 18 The Settings Button will open a Settings area which contains Display Mode, General Diagnostic Settings. The options presented first within the Settings screen are dependent on the mode selected, information on these can be found within each specific mode area. https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/03_- _VBOX_Touch_Screen_Layout...
  • Page 19 SD card. When screen capture is complete, VBOX Touch will emit an audible confirmation notification. If the screenshot has been saved unsuccessfully, for example no SD card is inserted or the card is full, the SD Card Icon at the top of the screen will flash 3 times and VBOX Touch will emit an audible error notification.
  • Page 20 Fwd/Back Buttons The Forward and Back arrow buttons are used to navigate through Display Mode and Settings screens. These can be used alongside swiping the screen left or right. https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/03_- _VBOX_Touch_Screen_Layout...
  • Page 21 04 - VBOX Touch Display Modes VBOX Touch has 4 modes available; Accel, Decel, Lap Timing and Speed. They allow you to conduct a range range of performance tests and functions, and can be changed by pressing the Mode Button at the bottom of the screen.
  • Page 22 • Custom test allowing the user to define their own configurable settings. • Screen displays time, run number, distance, Peak G and altitude difference. Units of measurement for speed or distance can be displayed in metric or imperial and easily swapped between. https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/04_- _VBOX_Touch_Display_Modes...

  • Page 23: Lap Timing

    Speed Display • VBOX Touch also works as a highly accurate digital speedometer, a handy feature for street driving. • Units can be set in kph or mph and display can show live speed, VMAX, average speed and distance including setting a target speed.
  • Page 24 The last selected Acceleration test will be displayed after each power cycle. It is possible to choose from either Speed or Distance parameters to start and end the test. Test results displayed on the screen of the VBOX Touch will remain on screen at the end of the test until the next start condition is met.
  • Page 25 Speed units used are dependent on what is selected within the General Settings area. Note: If the start condition is 0 km/h, VBOX Touch will use the Smoothed Speed Value to reset the test to avoid a test incorrectly resetting within noisy satellite reception areas.
  • Page 26 These values will start to populate once the start condition of the test is met. When the end condition is met, they will remain on screen until the start condition is met again. Along with pressing the Settings button, Accel tests can also be defined by double tapping on an existing test range header or result. https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/04_- _VBOX_Touch_Display_Modes/VBOX_Touch_-_Accel_Mode...
  • Page 27 • Right hand side: This contains the best results from the defined acceleration test ranges, either as time, distance or speed. These values can be reset by pressing the Reset button at the bottom of the screen. https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/04_- _VBOX_Touch_Display_Modes/VBOX_Touch_-_Accel_Mode...
  • Page 28 0–60, 0–100, 0–100–0 and 0–¼ mile. The currently selected test ranges are presented on the left hand side of the screen and will be remembered for future use, even if another mode is chosen. To define a range, press on the existing parameters. https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/04_- _VBOX_Touch_Display_Modes/VBOX_Touch_-_Accel_Mode...
  • Page 29 Test Type Select the Test Type button to choose between Speed, Distance or 0-Speed-0 (e.g. 0–100–0). Parameters displayed will depend on the test chosen. Speed Test Parameters Distance Test Parameters 0-Speed-0 Test Parameters https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/04_- _VBOX_Touch_Display_Modes/VBOX_Touch_-_Accel_Mode...
  • Page 30 Start Speed Keypad Example To save the value inputted, press the Confirm Button on the bottom right of the screen, or press the Cancel Button on the bottom left of the screen to return the Custom Test screen without saving. Notes: https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/04_- _VBOX_Touch_Display_Modes/VBOX_Touch_-_Accel_Mode...

  • Page 31: Result Type

    Accel option. It enables you to choose the test parameters and also includes other test options. Settings can be changed by pressing on the corresponding button next to an option. https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/04_- _VBOX_Touch_Display_Modes/VBOX_Touch_-_Accel_Mode...
  • Page 32 By default, an audible and visual alert signals when either the test end criteria, or the target speed is met within a 0-Speed-0 test. The VBOX Touch will beep and the 4 LEDs across the top of the device will flash green for 0.5 s.
  • Page 33 Test Results. Slope Correct If enabled, VBOX Touch will apply a DB Scanner slope correction method to all speed to speed or speed to distance acceleration test results presented on the screen. Notes: • Cannot be enabled if One Foot Rollout is Enabled.
  • Page 34 SD card. When screen capture is complete, VBOX Touch will emit an audible confirmation notification. If the screenshot has been saved unsuccessfully, for example no SD card is inserted or the card is full, the SD Card Icon at the top of the screen will flash 3 times and VBOX Touch will emit an audible error notification.
  • Page 35 • Maximum speed achieved during test run (km/h or mph) • Maximum acceleration achieved during test run (g) • Altitude difference between start of test and end of test (m or ft) It is possible take a screenshot of the test history by pressing the Screenshot Button https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/04_- _VBOX_Touch_Display_Modes/VBOX_Touch_-_Accel_Mode...

  • Page 36: Save Results

    SD card is inserted or the card is full, the button will flash 3 times and VBOX Touch will emit an audible error notification. If saved successfully, the file name will include the test type, the date and also the time, taken from the first completed run in that session.
  • Page 37 The last selected Deceleration test will be displayed after each power cycle. Speed parameters are used to start and end the test. Test results displayed on the screen of the VBOX Touch will reset when the vehicle moves after being stationary for a minimum of 3 seconds.
  • Page 38 A test can be reset by pressing the Reset button at the bottom of the screen. When the trigger is activated, 'ON' will be displayed next to the Trigger test header. https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/04_- _VBOX_Touch_Display_Modes/VBOX_Touch_-_Decel_Mode...
  • Page 39 - The external antenna should be used when conducting a brake trigger test. Decel Test If Decel is selected as the Test Type, preset and custom test options are available on the right hand side of the presented screen. https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/04_- _VBOX_Touch_Display_Modes/VBOX_Touch_-_Decel_Mode...

  • Page 40: Custom Test

    The currently selected test is highlighted on the screen and will be remembered for future use, even if another mode is chosen. Preset Tests The VBOX Touch is supplied preset with 5 speed Decel tests, press a test to confirm. The 60 – 0 test is selected by default. • 60 – 0 (km/h or mph) default •...
  • Page 41 You can then define the start and end speed conditions by pressing the corresponding buttons and using the keypad presented. Start Speed Keypad Example To save the value inputted, press the Confirm Button https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/04_- _VBOX_Touch_Display_Modes/VBOX_Touch_-_Decel_Mode...

  • Page 42: Trigger Test

    (below 2.5 km/h). IMPORTANT - The external antenna should be used when conducting a brake trigger test. Once 'Trigger' is selected as the Test Type, trigger settings are available on the right hand side of the presented screen. https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/04_- _VBOX_Touch_Display_Modes/VBOX_Touch_-_Decel_Mode...
  • Page 43 Minimum Trigger Speed Define the minimum trigger speed at which trigger activation becomes valid. If the trigger is detected below this speed, the test will not start. To change, press the current value and use the keypad presented. https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/04_- _VBOX_Touch_Display_Modes/VBOX_Touch_-_Decel_Mode...
  • Page 44 Note: The maximum input value for speed is 999.9 and can be entered up to 1 decimal place. MFDD Settings This area allows you to set up the start and end period of the MFDD (Mean Fully Developed Deceleration) analysis period. https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/04_- _VBOX_Touch_Display_Modes/VBOX_Touch_-_Decel_Mode...
  • Page 45 • s_08 is the distance at which the speed is v_08. MFDD can be also calculated using Speed by tapping the Percentage label until it reads Speed and entering the required values. To change any values, press the current value and use the keypad presented. https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/04_- _VBOX_Touch_Display_Modes/VBOX_Touch_-_Decel_Mode...
  • Page 46 MFDD From Speed Keypad Example To save the value inputted, press the Confirm Button on the bottom right of the screen, or press the Cancel Button on the bottom left of the screen to return to the Settings screen without saving. https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/04_- _VBOX_Touch_Display_Modes/VBOX_Touch_-_Decel_Mode...
  • Page 47 The Decel Mode settings screen can be accessed by selecting the Settings Button on the bottom left of the screen and then selecting the Decel option. It enables you to choose the test parameters and also includes other test options. https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/04_- _VBOX_Touch_Display_Modes/VBOX_Touch_-_Decel_Mode...
  • Page 48 Alert at End By default, an audible and visual alert signals when the test end criteria is met. The VBOX Touch will beep and the 4 LEDs across the top of the device will flash green for 0.5 s.

  • Page 49: Test History

    SD card. When screen capture is complete, VBOX Touch will emit an audible confirmation notification. If the screenshot has been saved unsuccessfully, for example no SD card is inserted or the card is full, the SD Card Icon at the top of the screen will flash 3 times and VBOX Touch will emit an audible error notification.
  • Page 50 ◦ Test completion distance (km/h or mph) ◦ Maximum speed achieved during test run (km/h or mph) ◦ Maximum deceleration achieved during test run (g) ◦ Altitude difference between start of test and end of test (m or ft) • Trigger decel test: https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/04_- _VBOX_Touch_Display_Modes/VBOX_Touch_-_Decel_Mode...

  • Page 51: Save Results

    SD card is inserted or the card is full, the button will flash 3 times and VBOX Touch will emit an audible error notification. If saved successfully, the file name will include the test type, the date and also the time, taken from the first completed run in that session.
  • Page 52 Selecting the Reset Button on the bottom right of the screen will reset all test results shown on the current screen. When pressed, the LEDs will briefly flash green twice and the unit will emit an audible confirmation notification. https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/04_- _VBOX_Touch_Display_Modes/VBOX_Touch_-_Decel_Mode...
  • Page 53 VBOX Touch - Lap Timing Mode The Lap Timing Mode allows you to view Lap Timing information in relation to a set Start/Finish line. Information includes: live reference lap speed comparison (Delta-V), live reference lap time comparison (Delta-T), current reference lap time, last lap time, last lap time difference to best, session time and completed lap count.
  • Page 54 Lap Timing - Main Screen This is the default lap timing screen and displays live Lap Timing information in relation to a set Start/Finish Line, Separate Start and Finish Lines or a Standing Start Separate Finish Line, and a Reference Lap. https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/04_- _VBOX_Touch_Display_Modes/VBOX_Touch_-_Lap_Timing_Mode...
  • Page 55 • If the current lap is the same speed as the reference lap, the LEDs will be off. The main lap timing screen can be reset by pressing the Reset button at the bottom of the screen or by pressing and holding on the screen. https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/04_- _VBOX_Touch_Display_Modes/VBOX_Touch_-_Lap_Timing_Mode...
  • Page 56 5 seconds after a lap has been completed if a rolling lap time is being shown. If the start/finish line has yet to be crossed or a lap hasn't been completed, it will not be shown. https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/04_- _VBOX_Touch_Display_Modes/VBOX_Touch_-_Lap_Timing_Mode...
  • Page 57 • The vehicle must be moving >0.8 km/h and the unit have satellite lock to set a Start/Finish Line. • If start/finish line setting is cancelled, any live lap prediction for the current lap will be lost and unavailable for use. https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/04_- _VBOX_Touch_Display_Modes/VBOX_Touch_-_Lap_Timing_Mode...
  • Page 58 Creating a Reference Lap A reference lap is required for VBOX Touch to calculate Delta-T and Delta-V lap timing values. VBOX Touch will automatically begin to create a reference lap once the Start/Finish line is crossed or movement is detected in...
  • Page 59 Lap Timing option. It is split in to 2 pages and enables you to choose the lap timing parameters. The different pages can be accessed by selecting the Forward and Back arrows on the bottom right of the screen or by swiping the screen left or right. https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/04_- _VBOX_Touch_Display_Modes/VBOX_Touch_-_Lap_Timing_Mode...

  • Page 60: Select A Track

    To return to the main screen, select the Exit Button on the bottom left. Select a Track VBOX Touch has an inbuilt track database containing a vast number of circuits throughout the world, a list of the currently supported circuits can be found here.
  • Page 61 Finish line when moving, overwriting the finish line detected within the circuit layout. A separate finish line must be set if you are using Standing Start Mode. More information about manually setting Finish line can be found above. https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/04_- _VBOX_Touch_Display_Modes/VBOX_Touch_-_Lap_Timing_Mode...
  • Page 62 • If finish line setting is cancelled, any live lap prediction for the current lap may be lost and unavailable for use. Load a Track Database The Track Database installed within the VBOX Touch is updated whenever a new firmware file is uploaded on to the https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/04_-...
  • Page 63 If there are splits stored within the file, these will also be uploaded to the unit, up to a maximum of 10 gates/splits. Note: When a new Start/Finish or Finish line gate is loaded, all existing lap timing values will be cleared and the new lap https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/04_- _VBOX_Touch_Display_Modes/VBOX_Touch_-_Lap_Timing_Mode...

  • Page 64: Gate Width

    Note: Width can be entered up to 1 decimal place. This option is particularly useful if the VBOX Touch is not detecting the correct number of laps. When racing at a very narrow circuit where the pit lane is right next to the start line, it could be possible to trigger lap timing within the pit lane, giving an incorrect number of laps.

  • Page 65: Standing Start

    When disabled, the previous lap time will be displayed. Note: Enabled by default. Standing Start When Standing Start is Enabled, VBOX Touch can use the position at the start of movement to trigger lap timing. This is particularly suitable for sprint style events.
  • Page 66 Using the default 5 km/h setting as an example: LEDs will show bright green Current lap is >5 km/h quicker than the reference lap LEDs will show dull green Current lap is 2.5 km/h quicker than the reference https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/04_- _VBOX_Touch_Display_Modes/VBOX_Touch_-_Lap_Timing_Mode...

  • Page 67: Reset Data

    5 seconds by pressing the screen. After 5 seconds, the LEDs will briefly flash green twice and the unit will emit an audible confirmation notification. Fix the Reference Lap https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/04_- _VBOX_Touch_Display_Modes/VBOX_Touch_-_Lap_Timing_Mode...
  • Page 68 If confirmed, a load success screen will briefly display to show that it was loaded successfully. If there are splits stored within the file, these will also be uploaded to the unit, up to a maximum of 10 gates/splits. https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/04_- _VBOX_Touch_Display_Modes/VBOX_Touch_-_Lap_Timing_Mode...
  • Page 69 REF LAPS folder on the SD card. A save success screen will briefly display to show that it was saved successfully. If a reference lap file already exists on the SD card, VBOX Touch will display an overwrite cancel screen, which gives you 5 seconds to cancel the overwrite by pressing the screen.
  • Page 70 SD card. When screen capture is complete, VBOX Touch will emit an audible confirmation notification. If the screenshot has been saved unsuccessfully, for example no SD card is inserted or the card is full, the SD Card Icon at the top of the screen will flash 3 times and VBOX Touch will emit an audible error notification.
  • Page 71 • Time difference from fastest lap It is possible take a screenshot of the lap history by pressing the Screenshot Button To return to the main screen, select the Exit Button on the bottom left of the screen. https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/04_- _VBOX_Touch_Display_Modes/VBOX_Touch_-_Lap_Timing_Mode...
  • Page 72 SD card is inserted or the card is full, the button will flash 3 times and VBOX Touch will emit an audible error notification. If saved successfully, the file name will include the date and the time when saved. Along with the lap history information described above, the results file also incudes the date and the time when saved.
  • Page 73 VBOX Touch - Speed Display Mode The Speed Display Mode allows you to view live speed data, selectable via 3 screens; Speed, VMAX and Average Speed. It is accessed by pressing the Mode Button at the bottom of the screen and selecting Speed.
  • Page 74 This screen displays the Absolute Top Speed reached until the Reset Button is pressed at the bottom of the screen. If a Target Speed is selected within the Speed Settings, it will be displayed in grey underneath the VMAX. https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/04_- _VBOX_Touch_Display_Modes/VBOX_Touch_-_Speed_Display_Mode...
  • Page 75 The screen can be reset at any time by pressing the Reset Button at the bottom of the screen. If a Target Speed is selected within the Speed Settings, it will be displayed in grey underneath the Average Speed. https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/04_- _VBOX_Touch_Display_Modes/VBOX_Touch_-_Speed_Display_Mode...

  • Page 76: Decimal Places

    Speed option. It enables you to choose between speed display options. To return to the main screen, select the Exit Button on the bottom left. Decimal Places https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/04_- _VBOX_Touch_Display_Modes/VBOX_Touch_-_Speed_Display_Mode...

  • Page 77: Avg Mode

    • Continuous: Average speed will start to calculate as soon as an SD card is inserted and initialised. • Moving: Average speed will start to calculate as soon as a speed over 0.8 km/h is detected. calculations will stop when speed is less than 0.8 km/h. https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/04_- _VBOX_Touch_Display_Modes/VBOX_Touch_-_Speed_Display_Mode...
  • Page 78 Enabling one, or both of the alerts will set the target speed and also allow you to access the sub menu where you can define the target speed condition by pressing the value box and then using the keypad presented. Target Speed Keypad Example To save the value inputted, press the Confirm Button https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/04_- _VBOX_Touch_Display_Modes/VBOX_Touch_-_Speed_Display_Mode...
  • Page 79 SD card. When screen capture is complete, VBOX Touch will emit an audible confirmation notification. If the screenshot has been saved unsuccessfully, for example no SD card is inserted or the card is full, the SD Card Icon at the top of the screen will flash 3 times and VBOX Touch will emit an audible error notification.
  • Page 80 05 - VBOX Touch Settings The VBOX Touch Settings menu is available by selecting the Settings Button on the bottom left of the screen when within a mode. A Select Settings Screen is then presented, allowing to you choose Mode Specific Settings...

  • Page 81: Mode Settings

    Selecting again will return to the main screen. Mode Settings The options presented first within the Settings screen are dependent on the Display Mode Selected, information on these can be found within each specific mode area. https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/05_- _VBOX_Touch_Settings...

  • Page 82: General Settings

    ◦ Continuous: The VBOX Touch will start logging as soon as an SD card is inserted and initialised. ◦ Moving (default): The VBOX Touch will start logging as soon as an SD card is inserted and a speed over 0.5 km/h is detected.
  • Page 83 ▪ A new data file is created every time the VBOX Touch starts/stops logging, data is not appended to an existing data file. ▪ Continuous logging mode should be selected if you are using a Hand Held Start/Stop Logging Switch (RLVBACS010) to control logging.

  • Page 84: Date And Time Settings

    To save the value inputted, press the Confirm Button on the bottom right of the screen, or press the Cancel Button on the bottom left of the screen to return the Time Settings screen without saving. https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/05_- _VBOX_Touch_Settings...
  • Page 85 To save the value inputted, press the Confirm Button on the bottom right of the screen, or press the Cancel Button on the bottom left of the screen to return the Time Settings screen without saving. Note: The maximum input value is 99. > https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/05_- _VBOX_Touch_Settings...
  • Page 86 • Sync to GPS: This feature will synchronise the internal real time clock (RTC) to GPS time as long as the unit has obtained GPS time (no GPS time is indicated by a satellite icon), isn't moving and isn't logging. When pressed, a synchronisation progress screen is presented. https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/05_- _VBOX_Touch_Settings...

  • Page 87: Serial Port Settings

    This menu contains serial output and RTK input settings. Serial Output Serial output is available on the top CAN/Serial port of the VBOX Touch, as shown in the image on the right hand side of the Serial Port Settings. https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/05_- _VBOX_Touch_Settings...
  • Page 88 • Output Mode: If required, choose the output mode of the serial port, selectable as 'VBOX Stream', 'Lap Timing' or 'Disabled' (default). VBOX Stream allows you to connect VBOX Touch with a computer using an RLCAB001 and conduct online testing with VBOX Test Suite, more information on this is available here.
  • Page 89 The satellite icon at the top of the screen is the quickest way to determine if the unit has a valid satellite lock. When lock is acquired, it will display as solid green . When there is no satellite lock, the icon will flash red https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/05_- _VBOX_Touch_Settings...

  • Page 90: Gps Information

    GPS Information • Cold Start: Press this button to perform a cold start on the VBOX Touch. This means the receiver will clear any data currently stored within its internal memory. It may be required to do this when the GPS engine has locked up or the VBOX Touch is struggling to acquire satellite lock.
  • Page 91 VBOX Touch Accuracy Comparison The VBOX Touch RTK variant improves on the positional accuracy of the standard unit from 2.5 m to up to 1 cm. Trigger brake stop accuracy is also improved from ±20 cm to ±5 cm. More details on these accuracies can be seen below.
  • Page 92 Connection to an NTRIP Modem Connect the RLCAB170 cable from the bottom Hirose connector on the NTRIP Modem to the bottom CAN/Serial port of the VBOX Touch. Ensure that the NTRIP Modem is correctly configured for use before connecting to the unit. https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/06_-_VBOX_Touch_RTK...
  • Page 93 Connection to a Local DGNSS Base Station VBOX Touch RTK receives RTCM correction data from a telemetry radio module which acts as receiver for information transmitted by the Racelogic DGNSS Base Station. It is connected to the bottom CAN/Serial port of the VBOX Touch via an RLCAB005.
  • Page 94 • If you are using a Static Base Station: Ensure NTRIP Mode is 'Disabled' and then select the correct baud rate, this setting should be either '115200' for a Racelogic blue boxed radio or '38400' for a Satel grey boxed radio.
  • Page 95 'GNSS Selection' within the 'General Settings' screen. More information on this is available here. Checking You Have RTK Lock The status of the DGNSS lock within a VBOX Touch RTK can be seen on screen via the Satellite Icon. Solid Green - Standalone Flashing Red - No positional accuracy;...
  • Page 96 • RTK FIXED: Position computed from GNSS corrected by RTK. Fixed means the integer ambiguity is established and the optimum position correction is applied resulting sub 2 cm relative accuracy in good conditions. https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/06_-_VBOX_Touch_RTK...

  • Page 97: Viewing Live Data

    07 - VBOX Touch Data Analysis Software Viewing Live Data VBOX Touch can be connected directly to a computer running our next generation of data analysis software VBOX Test Suite in order to view live data and perform tests. To connect to VBOX Test Suite, please follow the steps below.
  • Page 98 VBOX Test Suite Software, it can be downloaded from the VBOX Automotive Website if required. 6. Navigate to the 'Home' tab, select the 'Online' button and choose the correct COM port for VBOX Touch from the drop down menu. https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/07_- _VBOX_Touch_Data_Analysis_Software...
  • Page 99 Once the software is connected to VBOX Touch, the dashboard gauges will automatically start to display the data being sent live over the VBOX's serial stream. In this Online mode, Start, Stop and Reset buttons will appear on the dashboard. These buttons are used to start, stop and reset any open tests.

  • Page 100: Recorded Data

    More information on viewing live data and performing tests using VBOX Test Suite can be found here. Recorded Data If you do not need to conduct live testing, a recorded session will also be saved within the SD card as a .vbo file, which can be analysed later within the software. https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/07_- _VBOX_Touch_Data_Analysis_Software...
  • Page 101 How to update the VBOX Touch Firmware. Occasionally Racelogic will release new versions of these Racelogic will release new versions of firmware (internal applications, often to introduce new features code) for the VBOX Touch, often to introduce new features VBOX Touch - Updating the Track Database How to update the track map database within the VBOX Touch.
  • Page 102 VBOX Touch - EC Declaration of Conformity https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/08_- _VBOX_Touch_Technical_Properties/VBOX_Touch_-_EC_Declaration_of_Conformity...
  • Page 103 VBOX Touch - PIN OUTS Right side view of VBOX Touch Connector 1 - GNSS Antenna Function Centre RF Signal/Power for active antenna Chassis Ground https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/08_- _VBOX_Touch_Technical_Properties/VBOX_Touch_-_PIN_OUTS...
  • Page 104 Connector 2 - D IN / PPS (Lemo 3 PIN) Digital In and PPS Connector Function Ground Event/Brake Trigger Connector 3 - CAN / SERIAL (Lemo 5 PIN) Isolated CAN bus with active 120 ohm terminating resistors Function RS232 Tx RS232 Rx https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/08_- _VBOX_Touch_Technical_Properties/VBOX_Touch_-_PIN_OUTS...
  • Page 105 Function CAN High CAN Low Power Chassis Ground Connector 4 - CAN / SERIAL (Lemo 5 PIN) Isolated CAN bus with active 120 ohm terminating resistors Function RS232 Tx RS232 Rx CAN High CAN Low Power Chassis Ground https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/08_- _VBOX_Touch_Technical_Properties/VBOX_Touch_-_PIN_OUTS...
  • Page 106 Connector 5 - POWER (Lemo 2 PIN) Function Power Ground Chassis Ground https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/08_- _VBOX_Touch_Technical_Properties/VBOX_Touch_-_PIN_OUTS...

  • Page 107: Gnss Specifications

    VBOX Touch - Technical Specification Specifications GNSS Specifications Velocity Accuracy 0.1 km/h (averaged over 4 samples) Update Rate 10 Hz Maximum Velocity 1600 mph Minimum Velocity 0.5 km/h Resolution 0.01 km/h Distance Accuracy 0.05 % (<50 cm per km) Resolution...
  • Page 108 Accuracy (with SBAS)* H: 1 m CEP Update Rate 10 Hz Resolution 0.00185 m Position - VBOX Touch RTK Accuracy (Standalone)* H: 1.5 m CEP Accuracy (with SBAS)* H: 1 m CEP • H: 1 cm + 1 ppm CEP Accuracy (with RTK)* •...

  • Page 109: Environmental And Physical

    • Rubber cover: 141.5 mm x 103 mm x 36 mm (approximate) • Unit: 375 g Weight • Rubber cover: 75 g Operating Temperature -20°C to +60°C Storage Temperature -20°C to +80°C Mounting Richter mounting system or ¼” 20 TPI UNC https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/08_- _VBOX_Touch_Technical_Properties/VBOX_Touch_-_Technical_Specification...

  • Page 110: Touch Screen

    Touch Screen Size 4.3” TFT Capacitive Touch Resolution 480 x 800 pixels TFT LCD Display Colours 262K colours (18 bit) Dimensions https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_User_Guide/08_- _VBOX_Touch_Technical_Properties/VBOX_Touch_-_Technical_Specification...
  • Page 111 VBOX Automotive Website. Select the image of the app you would like/are using to download the latest file. If you are using the standard functionality of VBOX touch, click on the image of the 'Performance App' to download the latest file.

  • Page 112: Update Procedure

    VBOX Touch - Updating the Firmware Occasionally Racelogic will release new versions of firmware (internal code) for the VBOX Touch, often to introduce new features. Information about the latest firmware update can be found found here. New firmware is loaded into VBOX Touch using an SD card.
  • Page 113 - and also to update any older tracks with new layouts. The Track Database installed within the VBOX Touch is updated whenever a new firmware file is uploaded on to the unit. However, you can also independently update the Track Database by pressing the Load button within the Timing Settings menu.
  • Page 114 Button. 7. The VBOX Touch will start to load the file, which will update the tracks list but not overwrite any existing track information. Progress of the track database update will be displayed via the LEDs; each lit LED will represent 25% of the process with all LEDs extinguishing when the process is complete.
  • Page 115 To view the latest track list, click on the image below and use the Country dropdown menu. https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_Updates/VBOX_Touch_- _Updating_the_Track_Database...
