Parameter
yy
s
dd
TT
cc
User_Guide_%E2%80%93_VBOX_Touch_V2/07_Technical_Properties_%E2%80%93_VBOX_Touch_V2/VBOX_Touch_-
Number of bytes
2
1
2
2
2
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_V2/
Description
Longitudinal acceleration
Signed integer, 0.01 g per bit.
Range (-32768, 32767).
Solution type
Enumeration as signed integer.
• -1: No data
• 0: No solution
• 1: Stand alone
• 2: Code differential
• 3: RTK Float
• 4: RTK Fixed
• 5: Fixed position
• 6: IMU coasting
Date
DOS format.
• Bits 0–4: Day of month Range
(1, 31).
• Bits 5–8: Month Range (1, 12).
• Bits 9–15: Years since 1980
Range (0, 128).
Time since trigger event
Unsigned integer, 0.000000001
seconds (i.e. 1 ns) per bit. Range
(0, 429496729516).
Checksum
Standard Racelogic
communications CRC
calculation, See example below.
