VBOX Touch V2 Lap Timing Mode - Quick Start Guide
VBOX Touch features a 25 Hz GNSS receiver and a responsive colour touchscreen. The Lap Timing Mode allows you
to view live Lap Timing information in relation to a set Start/Finish line.
Two Lap Timing screens are available; the
live reference lap time comparison (Delta-T), current reference lap time, last lap time, last lap time difference to best,
session time and completed lap count. The
time.
Registration
Please register your VBOX Touch so that Racelogic can
continue to provide you with notifications about the latest
software releases and firmware upgrades for your
Racelogic product, and offer technical support.
Register your device here.
What is in the box?
When you purchase a VBOX Touch Motorsport V2 (RLVBTOUCH-M), you will find the following items when you open
the box:
Main
Screen, which contains live reference lap speed comparison (Delta-V),
Basic Screen
https://en.racelogic.support//Product_Info/Performance_Meters/VBOX_Touch/VBOX_Touch_V2/
Quick_Start_Guides_%E2%80%93_VBOX_Touch_V2/VBOX_Touch_V2_Lap_Timing_Mode_-_Quick_Start_Guide
contains either just a rolling lap time or a static previous lap
1
Advertisement
Table of Contents
Related Manuals for Racelogic VBOX Touch
Summary of Contents for Racelogic VBOX Touch
- Page 1 VBOX Touch V2 Lap Timing Mode - Quick Start Guide VBOX Touch features a 25 Hz GNSS receiver and a responsive colour touchscreen. The Lap Timing Mode allows you to view live Lap Timing information in relation to a set Start/Finish line.
-
Page 2: Optional Accessories
SD Card Format VBOX Touch is supplied with an 8 GB SDHC card in a FAT32 file format, which is the only file format supported. If you are looking to purchase a new SD card, it is recommended that any card used has a write speed of above 7 MB/s (4 MB/s absolute minimum) and a speed class of 10 (4 absolute minimum). - Page 3 SD card organisation. Power The VBOX Touch unit is powered by a power cable that is unterminated so that you can make a bare-wire connection to a power supply. The cable terminates in a 2-way connector that mates with the Power socket on VBOX Touch.
- Page 4 Every time after this, the last used display mode will be opened. Logging VBOX Touch logs data via an SD card inserted into the side of the unit. Depending on the Logging Strategy selected within the General Settings area, the unit will either log continuously or when movement is detected (default).
- Page 5 When the trigger switch is connected and latched, it is not possible to use the SD Card Icon to manually start or stop logging data. Logged Channels VBOX Touch logs channels to an inserted SD card within a .vbo file, channel information is available below: •...
- Page 6 CAN/Serial The top CAN/Serial port can be used to output serial Right Side information, allowing you to either connect VBOX Touch VBOX Test Suite via an RLCAB001 and conduct live testing, or output lap timing parameters. You can find more information about the Serial Output settings here.
-
Page 7: Satellite Reception
External Antenna (If Required) The placement of the GNSS antenna is crucial to the quality of the data recorded by VBOX Touch. Any metal close to a GNSS antenna can unpredictably disturb the signal due to interference from reflections of weak GNSS signals. - Page 8 Tall buildings or trees can block GNSS signals, causing a reduction in the number and quality of satellites being tracked, leading to inaccurate position measurements and a noisy velocity signal. GNSS works best in open areas/ Avoid tree-lined roads https://en.racelogic.support//Product_Info/Performance_Meters/VBOX_Touch/VBOX_Touch_V2/ Quick_Start_Guides_%E2%80%93_VBOX_Touch_V2/VBOX_Touch_V2_Lap_Timing_Mode_-_Quick_Start_Guide...
-
Page 9: Gps Coldstart
GPS Coldstart If VBOX Touch is struggling to acquire a satellite lock, a GPS coldstart may be required. This may be necessary when the unit hasn’t been used for several days or has dramatically moved location since its last use. - Page 10 LEDs; each lit LED will represent 25% of the process with all LEDs extinguishing when the process is complete. When a Track Layout is changed, the LEDs will briefly flash green twice. https://en.racelogic.support//Product_Info/Performance_Meters/VBOX_Touch/VBOX_Touch_V2/ Quick_Start_Guides_%E2%80%93_VBOX_Touch_V2/VBOX_Touch_V2_Lap_Timing_Mode_-_Quick_Start_Guide...
- Page 11 If a screenshot has been saved successfully, the LEDs will illuminate Screenshot yellow in sequence from left to right to display the progress of writing to the SD card. The LEDs will briefly Reset flash green twice when a screen has been reset. https://en.racelogic.support//Product_Info/Performance_Meters/VBOX_Touch/VBOX_Touch_V2/ Quick_Start_Guides_%E2%80%93_VBOX_Touch_V2/VBOX_Touch_V2_Lap_Timing_Mode_-_Quick_Start_Guide...
-
Page 12: Screen Overview
Main screen example Setup 1. Connect the power via the Power socket. 2. Insert the SD card into the Side of the Unit. The SD Card Icon should display as green as long as the card has free space. https://en.racelogic.support//Product_Info/Performance_Meters/VBOX_Touch/VBOX_Touch_V2/ Quick_Start_Guides_%E2%80%93_VBOX_Touch_V2/VBOX_Touch_V2_Lap_Timing_Mode_-_Quick_Start_Guide... - Page 13 Test Suite or output lap timing parameters, go to Serial Output within the Serial Port Settings and change the Output Mode to either VBOX Stream (live testing with VBOX Test Suite) or Lap Timing. Note: Ensure correct hardware connections are made. https://en.racelogic.support//Product_Info/Performance_Meters/VBOX_Touch/VBOX_Touch_V2/ Quick_Start_Guides_%E2%80%93_VBOX_Touch_V2/VBOX_Touch_V2_Lap_Timing_Mode_-_Quick_Start_Guide...
- Page 14 11. Press the Exit Button to return to the Lap Timing screen. 12. Take the vehicle outside and wait for the VBOX Touch to gain satellite lock. The Satellite Icon should display as solid green. Note: The first time that the unit is used, it may take up to 15 minutes to fully acquire satellites. After this, it will usually take 1 to 2 minutes to acquire satellites.
- Page 15 14. The unit is now ready to display live Lap Timing values. Main Screen: • Once the start/finish line is crossed, VBOX Touch will automatically begin to create a reference lap. When a reference lap is being created, a 'Creating a Reference Lap' message is displayed within the Delta-T section and the reference lap section will show a rolling lap time.
- Page 16 Basic Screen: • VBOX Touch will display the current live lap time and when a new lap starts, the previous lap time will be displayed for 3 seconds before reverting to displaying the current live lap time. It is possible to just display the previous lap time by Disabling the Rolling Lap Time.
