Racelogic VBOX Touch V2 User Manual page 53

Note: Lap timing gates are bi-directional and can be triggered when passing through in either direction.
Lap Timing Mode Overview
There are 2 different Lap Timing screens which can be accessed by selecting the Forward
and Back
arrows on the bottom right of the screen or by swiping the screen left or right.
Lap Timing - Main Screen
This is the default lap timing screen and displays live Lap Timing information in relation to a set Start/Finish Line,
Separate Start and Finish Lines or a Standing Start and Separate Finish Line, and a Reference Lap.
User_Guide_%E2%80%93_VBOX_Touch_V2/05_Display_Modes_%E2%80%93_VBOX_Touch_V2/VBOX_Touch_V2_-
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_Touch/VBOX_Touch_V2/
_Lap_Timing_Mode
53
