03 LED Behaviour – VBOX Touch V2
The 4 LEDs at the top of the unit provide visual feedback dependent on what process is being performed:
Function
Accel/Decel Mode
Lap Timing Mode
Behaviour
If Alert at End is enabled, the LEDs
will flash green for 0.5 s once the
test end criteria are met.
The LEDs provide a live reference
lap speed comparison (Delta-V).
The current lap is > 5 km/h
quicker than the reference lap
The current lap is 2.5 km/h
quicker than the reference lap
The current lap is the same speed
as the reference lap
The current lap is 2.5 km/h
slower than the reference lap
The current lap is > 5 km/h
slower than the reference lap
The LEDs will illuminate blue during
the process of creating a Reference
Lap.
